DESCRIPTION OF THE DEVICE
Front
1
2
1
(1) Mounting brackets
(2) Fixation screws
(3) Mounting points for additional fixtures
(4) Spots, in sequence, with 10 W SMD 5050 4in1 QCL RGB/WW LEDs
Rear
5
6
(5) Power output fuse holder
(6) Power output for additional fixtures
(7) Rotary dial for brightness
(8) Display with operating buttons
(9) Microphone
(10) DMX input
(11) DMX output
(12) Wireless DMX port
(13) Safety eyelet
(14) Device fuse holder
(15) Power input
(16) Power output
(17) Spot connections
(18) Stand sleeve with fixation screw
