GB
Fitting the abrading disc
DANGER! Risk of injury! Never use dam-
aged abrading discs. Always check the
abrading disc for cracks or other damage
before fitting it.
Use only abrading discs whose permitted
rotational speed is at least as high as the
idling speed of the appliance (► Technical
data – p. 35).
WARNING! Risk of injury! The permitted
diameter for the abrading disc must always
be complied with (► Technical data –
p. 35).
CAUTION! Risk of injury! Use only abrad-
ing discs which are permitted for the mate-
rial being worked with.
► P. 3, item 3
– Press the spindle locking button on the top of
the tool and keep it pressed.
– Unscrew flange nut (9).
– Place the abrading disc onto the spindle. Com-
ply with the required installation position of the
abrading disc.
– Place the flange nut onto the spindle. Note the
installation position of the flange nut:
1. Flange pointing away from abrading disc: for thin
discs such as cutting discs.
2. Flange pointing towards abrading disc: for
thicker discs such as abrading discs.
– Tighten the flange nut using the face pin wrench
provided while pressing the spindle locking but-
ton.

Commissioning

Adjusting the protective bonnet
► P. 3, item 1
The protective hood must be adjusted so that it pre-
vents sparks and particles from being thrown in the
direction of the user.
– Loosen bolt (7).
– Adjusting the protective hood
– Retighten bolt (7).

Operation

DANGER! Risk of injury! Let the appli-
ance idle for a few seconds before use.
When vibrations start to occur, replace the
abrading disc immediately.
WARNING! Risk of injury! The appliance
must be used only with the additional hand
grip fitted and the protective hood correctly
adjusted.
Check before switching on!
Check the safe condition of the appliance:
34
– Check it for visual defects.
– Check that all parts of the machine have been
securely fitted.
Switching on/off
WARNING! Risk of injury! After switching
off, the appliance continues to run on for a
few seconds. Wait until the abrading disc
has come to a stop before laying the appli-
ance down.
NOTICE! Risk of machine damage! The
motor can overheat when running at low
speeds under continuous heavy load. Cool
off the motor by running at high speed with-
out a load.
Note: In case of a loss of power, an under-
voltage relay is triggered. This prevents the
product from restarting by itself as soon as
the power is restored.
To switch on again the product must be
turned off at the main switch and then
turned back on.
– Set the required revolutions using the regula-
tor (1).
– Switching on: Press switch-on safety lock (2)
and On/Off switch (3) simultaneously.
– Switching off: Release On-Off switch (3).
Tips on use
DANGER! Risk of injury! Never use cut-
ting discs for abrading.
CAUTION! Risk of injury! The abrading
disc and work piece become very hot dur-
ing use. Let the abrading disc and work
piece cool down completely before touch-
ing them.
WARNING! Risk of injury! Always grind
with the specified surfaces:
• Cutting discs: Peripheral surface;
• Grinding disc, grinding wheel: Side sur-
face.
CAUTION! Risk of injury! The abrading
disc and work piece become very hot dur-
ing use. Let the abrading disc and work
piece cool down completely before touch-
ing them.
• Always clamp the work piece firmly.
• Never tilt the appliance when cutting materials.
• Never apply excess pressure to the appliance.
