Product introduction

LED power indicator
Indicator lights green: e battery is fully charged
Indicator flashes green: e battery is charging or
network connection configuration mode is active
Indicator flashes yellow: Low battery level
Indicator lights red: Very low battery level
Indicator flashes red: Abnormalities in the
operation of the device
Tank lid / Cleaner inlet
Cleaner tank
Ultrasonic spray nozzle
It is normal for the water to build up around
the nozzle. Wipe it o after cleaning.
Speaker
Handles
Tracks
Air inlet
www.Welltec.pro
Air outlet
Power button
Long press (at least 3 seconds):
Turn on / off the device
Short press:
Start / stop cleaning
Short and quick press 3 times
in a row:
WiFi connection mode
Power cord socket
Safety rope attachment
socket
Air outlet
Edge sensors
34
Product introduction
Automatic spraying
Manual spraying
X2 double cleaning mode
Note:
• If you want to issue a new order to the robot while it's cleaning, first stop the cleaning by pressing the
Start/Stop button to prevent incorrect operation.
• Take out the battery insulation film in the battery compartment before use.
www.Welltec.pro
Manual control
Start/Stop cleaning
Automatic cleaning to the left
Start cleaning left and then horizontally from top to
bottom
Automatic cleaning upwards
Move to the top edge and start cleaning to the right
and then horizontally from top to bottom
Automatic cleaning to the right
Start cleaning to the right and then horizontally from
top to bottom
Battery compartment
