Features
There are two versions of the system board D1571 with the part numbers S26361-D1571-A50 and
S26361-D1571-A10. The two versions differ in the chipset assembling.
•
one processor socket for an Intel Northwood/Prescott processor with 2.6 GHz and higher,
socket 478, with 400/800 MHz Front Side Bus, up to 1 MB second level cache
•
4 slots for main memory. DDR 333/ DDR 400 (unregistered) SDRAM memory modules for
256 Mbyte up to 4 Gbyte main memory
•
on riser card:
one 64 bit PCI slot with 66 MHz (maximum length 315 mm)
one 64 bit PCI slot with 66 MHz (low-profile)
•
SATA controller PDC 20139u (S26361-D1571-A10): system board supports RAID and hot-plug
hard disks
•
Without SATA controller PDC 20139u (S26361-D1571-A50): system board supports LSI
HostRAID (SW implementation), but no hot-plug hard disks
•
Screen controller ATI Rage XL VGA onboard 8 Mbyte SDRAM memory
•
2 LAN controllers: CSA/Intel 82547EI and Intel 82541EI
•
super I/O controller SMSC 47192
•
Server Management by BMC (FSC system)
•
two SATA interfaces
•
floppy port (26 pin for foil cable)
•
one external serial port (COM1), default setting is "disabled"
(you will find further information in the "D1571 Setup Utility" description)
•
three external USB ports, one on the front and two on the rear side
•
two external RJ45 LAN ports
•
two external PS/2 interfaces for keyboard and mouse
•
temperature and system monitoring
