Entries in OSD menu:
Current X:
Horizontal position of this particular monitor in the video wall.
Current Y:
Vertical position of this particular monitor in the video wall.
Total X:
Overall number of horizontal monitors composing the video wall (max. 12).
Total Y:
Overall number of vertical monitors composing the video wall (max. 12).
Left edge:
Adjustment (fine tuning) to the left for each individual monitor in the video wall.
Up edge:
Adjustment (fine tuning) to the top for each individual monitor in the video wall.
Right edge:
Adjustment (fine tuning) to the right for each individual monitor in the video wall.
Down edge:
Adjustment (fine tuning) to the bottom for each individual monitor in the video wall.
