Throttle Interface
3. Open the MOZA Pit House software suite to preview and confirm the status of each pedal.
If the device is still colored grey or does not respond after using the pedal, please unplug
the base, close the MOZA Pit House, restart your PC and reconnect the base, finally
opening the MOZA Pit House again.
4. The pedal input (start, end point, stroke detail) can all be adjusted within the MOZA Pit
House suite.
Pedal Spacing Adjustment
Select the relevant screw holes of the pedal you wish to adjust, loosen the pedal, and move
it either left of right to align the pedal as you wish, tightening the screws to lock the pedal
into place (adjusting the distance between the throttle, brake and clutch is the same).
Plate Height Adjustment
Using a 2.5mm hexagon wrench, adjust the screws on the pedal board counterclockwise,
then use a 7mm open-end wrench to remove the back nut and board screw. You may then
move the board up and down to adjust the height according to your needs, then screwing
the back nut and board screw back into place. Adjustments to the throttle, brake and
clutch are done in the same way.
wheelbase interface
4
Clutch interface
