Coding Switch/Modes of Operation
To select the channel and/or mode of operation
• Turn the coding switch to the desired position in accordance with the following
table:
Position
0 no function
1 learning mode, Channel 1
2 learning mode, Channel 2
3 learning mode, Channel 3
Modes of Operation
Channel 1
4 Switch
5 Pushbutton Switch
6 Pushbutton Pushbutton Switch
7 Pushbutton Pushbutton Pushbutton
8 Blind
9 Blind
Channel 2 Channel 3
Switch Switch
Switch
Blind Switch
Blind Pushbutton
