English

Use

Adjusting the support feet (Fig� G)
The equipment is equipped with 8 angular end
caps. If the equipment feels unstable, wobbly, or
not levelled well, these end caps can be used to
make the required correction.
- To level the trainer, turn the 8 angular end caps
located on the rear stabilizer tube.
- Each aspect sets the machine in a different
height level.
�� QUICK TIP
• It is easier to do this with two persons, so
one person can tilt the equipment, while the
other makes the needed adjustment.
‼ NOTE
• The machine is the most stable when all
support feet are turned fully in. Therefore
start to level the machine by turning all
support feet fully in, before turning out the
required support feet to stable the machine.
• The centre foot suppose to be a few
millimetres from the floor when not seated on
the rower seat.

Adjusting resistance

To increase or decrease resistance, turn the
adjustment knob at the top of the handlebar
support tube clockwise (+ direction) to increase
resistance and counter-clockwise (- direction) to
decrease resistance.
The scale above the knob (1-8) helps you find and
set a suitable resistance.
‼ NOTE
• Due to the strong magnets used for the
brake system, there may be no noticeable
change in resistance when the resistance
level is reduced by just one step from setting
7 or 8.
In this situation, we recommend first reducing
the resistance to setting 5 or lower, and then
increasing it to the desired setting.
18
Folding (Fig� E)
- Loosen the fixation knob (#55).
- Fold the aluminium rail.
- Securing aluminium rail with the lock pin.
Unfolding
same as in folding, but in reverse following order.
‼ NOTE
• Support the slide rail when lowering all the
way down.

Replacing the batteries (Fig F-2 )

The console is equipped with 2 AA batteries at
the rear of the console.
To fit/ Replace the batteries
- Remove the cover. (Located on the back side).
- Remove the old batteries.
Only valid when replacing the batteries for fresh
ones.
- Insert the new batteries.
Make sure that batteries match the (+) and (-)
polarity markings.
- Mount the cover.
‼ NOTE
• Empty batteries should always be recycled
per your Local legal regulations to save the
environment.
⚠ WARNING
• Do not expose batteries to big temperature
changes to prevent the batteries from
leaking.
• To prevent your batteries from leaking, take
them out if you plan on not using your device
for longer periods of time.
• When inserting multiple batteries into a
device, always use the same brand, the same
type, and the same energy level.
