GES R2
Preparatory work
See Fig.
1. Insert the partition
.
3
Installing and mounting the socket
See Fig.
1. Attach the sockets to the split 1x Modul 45 cover plate (B1).
2. Electrically connect the installation cable
3. Insert the strain relief in the 1x Modul 45 cover plate (B2).
4. Clamp the installation cable in the strain relief (B3).
5. Engage the mounted 1x Modul 45 cover plate in the installation
socket (B4).
Installing and mounting the data module
See Fig.
1. Attach the sockets to the 1x Modul 45 cover plate (C1).
2. Connect the installation cable for data connections to the data
socket
3. Insert the data socket into the data module from below (C2).
4. Engage the mounted 1x Modul 45 cover plate in the installation
socket (C3).
11.5.3

Installation with cover plate for 1.5x modules

1. Attach the British Standard sockets to the 1.5x cover plate (see
Fig. ,
2. Electrically connect the installation cable.
3. Insert the strain relief in the 1.5x cover plate.
4. Clamp the installation cable in the strain relief.
5. Engage the mounted 1.5x cover plate in the installation socket.
11.5.4

Installation of additional data cables

See Fig.
1. Connect the installation cable for data connections to the data
socket.
2. Insert the data socket into the mounting plate for data cables
from below.
3. Engage the mounting plate in the installation socket.
11.6

Final work on the installation socket

Tighten the three screws (see Fig.
nings using the battery-operated screwdriver.
Installing/mounting the GES R2 floor socket
, A:
with the centring spigot
1
, B:
, C:
.
5
).
2
:
in the recess
2
.
4
, ) of the universal faste-
1
EN | 35
