CA 3000P1/24v
FEATURES
• Mono output.
• Pulse Width Modulated (PWM) MOSFET Power Supply.
• Variable input sensitivity:
• Thermal-, Overload- and Shortcircuit
• Excellent muting circuitry assures no turn on/off 'pops'.
• Built-in Low Pass Filter
• Gold plated power connectors for optimal power distribution.
• European design and engineering.
• Gold plated speaker connectors for optimal signal output.
MOUNTING
The amplifier has to have at least 5 cm (2") ventilation space at all sides, to allow the heat to rise
away from the amplifier. Be sure that the power and signal cables can enter and leave the amplifier
in a straight line, to avoid the risk of malfunction. Always place the power- and signalcables
opposite sides of the vehicle to reduce any noises.
The amplifier should be protected from exposure to moisture and direct sunlight.
Mark the mounting surface using the amplifier as a template, then drill 2.5 mm (1/8") diameter
holes at the marked locations and mount the amplifier using the supplied self-tapping
INSTALLATION
Remember to always disconnect battery ground before working on a vehicle's electrical system!
Always place a fuse or circuit breaker no more than 30 cm (12") from the battery, no greater than
the fuse(s) of your amplifier for optimal protection.
GETTING YOUR POWER
• First, the +24V terminal is connected
least 15 mm2, and make sure that the connectors are of the same value.
- Don't forget the extra "Vehicle protection" fuse.
- The +24V terminal should
• Second, the ground terminal (GND) must be fastened securely to the chassis of the vehicle
with the same mm2 cable as the positive cable (the same amount of power has to run
through it). Ensure that all paint, undercoating
area where you want to make your ground connection to.
• Third, the last cable to connect is your remote turn-on (REM). Many radio-cassette
CD-players have an output terminal for connection
have such an output, a separate switch must be installed to control your amplifiers on/off
function.
RCA INPUT
• Connect the RCA-outputs
Take good care that you connect the Right output of your radio to a Right input of your
amplifier, and that you connect the Left output of your radio to a Left input of your amplifier.
Manual
RCA input 0.5V to 8V.
protection.
STARTED
directly to the battery of your car. Use a cable of at
NOT be connected to the
or any other insulation is removed from the
of the REM of an amplifier. If you don't
of your radio to the RCA input terminals of the amplifier.
· 3 ·
.3.
screws.
car fuse box.
and
at
