CARBEST l Acrylicglass hinged window RW Compact
INTRODUCTION
You have chosen a high quality product of the brand CARBEST. To ensure that you can enjoy this product for a long time, please read
the operating instructions carefully before using the product. Pay particular attention to the safety instructions and warnings in order
to avoid damage to the product and injuries.
These instructions are based on EU standards and regulations. Therefore, observe country-specific guidelines and laws when using
the product abroad.
Keep these instructions for future reference and pass them on to third parties if you sell the product.
Failure to follow the instructions in this manual may result in material damage or leakage and affect the function of the
window.
Also observe the safety instructions and requirements prescribed by the vehicle manufacturer / body builder!
Please contact our customer service if you have any questions, problems or suggestions in connection with this product. Please
always quote the item and invoice number, as well as the customer number (if available).
Service contact:
Reimo Reisemobil Centre GmbH
Boschring 10, 63329 Egelsbach
Phone: +49 6150 8662-370
Email: service@reimo.com

SCOPE OF DELIVERY

•Hinged window
•Mounting frame
•Mounting material (screws)

ACCESSORIES (OPTIONAL)

Interior frame with mosquito net and blackout
Outer dimension Colour white
W x H (mm) item number
377x544 318901
527x344 318911
527x394 319011
318921
527x494
627x494 318991
318931
727x344
727x444 319001
727x494 319021
827x494 318941
927x494 318951
318961
927x544
318971
1027x544

SAFETY INSTRUCTIONS

•CARBEST hinged window RW Compact is designed exclusively for installation in campervans, motorhomes and caravans.
•Please hire a specialist company to install the window if you do not have sufficient installation knowledge.
•Keep the window closed during rain, snowfall or strong wind.
•Before each trip, check that the window is undamaged and closed.
•If you notice any damage to the window (cracks, damage to the acrylic glass), contact a specialist workshop, your dealer or the
manufacturer immediately.
Item
number
31890
318910
31901
31892
31899
318913
31900
31902
31894
31895
31896
31897
Colour black Suitable for
item number. windows
318902 31890
318912 318910
319012 31901
318922 31892
318992 31899
318932 318913
319002 31900
319022 31902
318942 31894
318952 31895
318962 31896
318972 31897
Cutout size Outer Viewing appr.
W x H (mm) dimensions
W x H (mm)
350x500 378x528
500x300 528x328
500x350 528x378
500x450 528x478
600x450 628x478
700x300 728x328
700 x 400 728x428
700 x 450 728x478
800 x 450 828x478
900 x 450 928x478
900 x 500 928x528
1000x500 1028x528
5
Max. (kg)
Opening
W x H (mm)
290x430 73° 2,2
440x260 77° 2,1
440x290 38° 2,2
440x390 65° 2,8
540x390 68° 3,4
640x240 77° 2,9
640x340 52° 3,5
640x390 68° 3,6
740x390 66° 4,2
840x390 70° 4,7
840x440 70° 5,0
940x440 72° 5,4
