EN - USER MANUAL
Battery charger with jump starter P/N:04500
WARNING! ELECTRIC SHOCK can kill. • This document contains
general information about the topics discussed herein.This document is
not an application manual and does not contain a complete statement of
all factors pertaining to those topics. • This operation,and maintenance
of the charger and the employment of procedures described in this
document should be conducted only by qualified persons in accordance
with applicable codes,safe practices,and manufacturer's instructions.
• Misuse of equipment,and failure to observe applicable codes and safe
practices,can result in serious personal injury and property damage.
SAFETY PRECAUTIONS - READ BEFORE USING:
These original operating instructions / the device uses the following
pictograms:
Warning! Read
User's Manual!
Warning!
Warning! Risk
of fires and
burns!
Warning!
Explosion
hazard!
Warning!
Prevent rain,
indoor use!
Congratulations!
You have chosen high-quality device by our company. Familiarise yourself
with the product before using it for the first time. Carefully read the
following User's Manual or operating instructions and safety notices. Initial
operation of this tool must be performed by trained personnel.
1.1 SYMBOL USAGE:
It means Warning! There are possible hazards! Possible hazards are
described in the corresponding instructions.
It marks a special safety message.
This group of symbols means Warning! Possible
ELECTRIC SHOCK and HOT PARTS hazards. Consult
symbols and related instructions below for necessary actions to avoid the
hazards.
1.2 SYMBOL USAGE:
• The symbols shown below are used throughout this manual to call
attention to and identify possible hazards. When you see the symbol,
watch out, and follow the related instructions to avoid the hazard. The
safety information given below is only a summary of the more complete
safety information found in the Safety Standards. Read and follow all
Safety Standards.
• Only qualified persons should repair this unit.
• During operation, keep everybody, especially children, away.The charger
is not suitable for children or people who can't read and understand the
safety instructions. Store it out of the range of those people or children.
Don't let children play with the charger.
ELECTRIC SHOCK can kill.
Touching live electrical parts can cause fatal shocks.The input
power circuit and charger internal circuits are live when power
is on.
• Do not touch live electrical parts.
• Wear dry, hole-free insulating gloves and body protection.
• Disconnect input power before servicing this charger.
• Turn off power supply when not in use.
• Do not use worn, damaged, or poorly spliced cables.
• Do not drape cables over your body.
• Check the cables for damage before you use it.
• Warning: Under Function maintenance mode, it is strictly prohibited
to reversed polarity or wrong connection of the positive and negative
electrodes of the charging clip and the short circuit phenomenon, to
prevent damage to the battery and this equipment, to avoid causing
personal injury and other events.
• This appliance can't be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Cleaning and user maintenance shall not be made by children
without supervision.
• Remove all flammables within 5m of the charging.
• Watch for fire, and keep a fire extinguisher nearby.
• Connect work cable to the battery as close to the charging area as
practical to prevent charging current from traveling long, possibly
unknown paths and causing electric shock and fire hazards.
• Never charge a damaged battery.
• Don't put the charger on the battery during charging.
• Don't cover the battery charger.
• Only charge in well vented areas.
Dispose of packaging
• Battery acid can harm you, if you should have contact with battery
and device in an
acid go immediately to a doctor.
environmentally-
• There could be explosive gas during charging, you have to avoid sparks.
friendly way!
Warning! Risk of
electric shock!
Warning! Risk of hot
parts!
• Pacemaker wearers keep away.
• Wearers should consult their doctor before going near battery charging
operations.
Warning! STATIC
(ESD) can damage PC
boards.
Indoor use
MAINTENANCE MADE BY UNQUALIFIED PERSONS MAY CAUSE INJURIES
• Electrical devices should not be repaired by unqualified persons.
Improper repairs can cause serious injuries or even death during
applications.
• The service given by unqualified persons may cause electric shock and
operators can be injured seriously.
• Disconnect the supply before making or breaking the connections
to the battery.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or qualified persons in order to avoid
a hazard.
batteries. If the user is used for other purposes, it may cause danger,
personal injury or loss of property.
2. Under Function maintenance mode, it is strictly prohibited to
reversed polarity or wrong connection of the positive and negative
electrodes of the charging clip and the short circuit phenomenon, to
prevent damage to the battery and this equipment, to avoid causing
personal injury and other events.
• P/N:04500 is a charger with control software. It is suitable for charging
and trickle charging the following 12V or 24V rechargeable lead batteries
with electrolyte solution, AGM batteries, lead-acid batteries, or GEL
batteries. For example, 12V STD or 12V WET/MF/GEL batteries, 12V AGM
batteries, 24V AGM batterie, 24V STD or 24V WET/MF/GEL batteries.For
automotive batteries with 24V and different capacity and motorcycle
batteries with 12V and different capacity, you can also regenerate drained
batteries (depending on battery type).
• The charger features a protective circuit against overheating. Any
improper or incorrect use will void the warranty. The manufacturer is not
liable for damage caused by improperuse.
Note: The charger is not suitable for charging electric vehicles with
built-in rechargeable battery. Do not try to charge non-rechargeable
batteries with this charger.
• With engine start function. Under 12V or 24V, Max. 300A charging
current, 3s ON, 180s OFF, Max. 5 cycles.
• Don't use it for anything else.
• P/N:04500 charger is single phase, 230V~, 50Hz, battery charging power
source especially designed for 12V and 24V batteries charging.For 12V
batteries, 5A, 10A, 20A or 40A charging current can be selected. For 24V
batteries, 5A,10A or 20A charging current can be selected.
• The control of the charger is placed on to the panel for easy operation.
CHARGING can cause fire.
Hot parts can cause fires and burns. Check and be sure the area
is safe before doing any charging.
WARNING: Explosive gases. Prevent flames and sparks. Provide
adequate ventilation during charging.
HOT PARTS can cause severe burns.
• Do not touch hot parts by using your bare handed.
MAGNETIC FIELDS can affect pacemakers.
STATIC (ESD) can damage PC boards.
• Put on grounded wrist strap BEFORE handling boards or parts.
• Use proper static-proof bags and boxes to store, move, or ship
PC boards.
Warning!
1. This charger is only suitable for charging all kinds of lead-acid
2.1 GENERAL DESCRIPTION:
04500
P/N:
1
