Supplied Components

If any component should be missing, please contact your dealer.
 Liquid Crystal Display Monitor: 1
 Cable holder: 1
 Power cord
 Base: 1
 Signal cable (DisplayPort cable): 1
NOTE: Remember to save your original box and packing material to transport or ship the monitor.


Type and number of power cords included will depend on the country where the LCD monitor
is to be shipped.
Make sure all contents are in the box before starting monitor assembly.

Mounting precautions

• When moving the monitor, be sure to hold its sides or bottom. Do not hold the LCD panel or
buttons. This may cause product damage, failure, or injury.
• To attach a VESA-compliant mounting bracket, use M4 screws that are 6 mm to 10 mm longer than
the thickness of the mounting bracket.
6 - 10 mm
• Be sure to use a wall-mount bracket designed or designated for mounting the monitor.
• This monitor and bracket must be installed on a wall which can endure at least 4 times or more the
weight of the monitor.
Install by the most suitable method for the material and the structure.
• Do not use an impact driver.
• Do not use any screw holes other than those for mounting brackets, located on the rear of the
monitor, for installation.
Screws (M4)
Mounting bracket
Monitor mounting
100 mm
Screw holes for mounting brackets
