Callouts
5
1.
COMBO INPUT – XLR / 1/4" TRS input for connecting line-level or stereo headphone sources.
2.
INPUT SELECT SWITCH – Switches between Line (balanced/unbalanced line-level input) and Phones
(stereo headphone input).
3.
LEVEL TO AMP – Volume rotary knob to control the instrument to line signal level sent to the amp
output.
4.
GROUND LIFT – Switch for disconnecting pin-1 ground on the XLR input to eliminate hum or buzz
caused by ground loops (GROUND is the default setting).
5.
AMP OUTPUT – 1/4" TS unbalanced instrument-level output for connecting to a guitar amplifier,
pedalboard, or effects unit.
6.
MUTE SWITCH – Switch on and off to Mute amp output.
4
2
1
6
EN
FR
3
DE
ES
IT
