a
b
c
d
e
f
3 4
2
1
9 10
Quadrum Compact / Compact G
a
Reference laser outlet
b Prism head / laser beam outlet
c Control panel
d Infrared signal receptor
e Connection socket for power
pack/charger
f 5/8" thread
g Battery compartment
g
a
1 auto/slope function
2 LED auto/slope function:
LED off: automatic alignment
5
LED on: manual alignment
3 ON/OFF button
6
4 Operation indicator
7
5
Tilt function LED
8
6 Tilt function
7 Infrared signal receptor
8 Charge status
9
X-axis LED
10 Y-axis LED
11 Z-axis LED
23
EN
