Configuration examples mono mode
Configuration notes momo mode:
Mode
Mono A
(1-channel)
Attention: The crossover frequencies for the high- and lowpass must be set in the preconnected DSP /
DSP amplifier.
DSP / DSP
amplifier via
RCA / Cinch
or
HELIX V series
amplifier via
V-AMP Link
24
Amplifier input
Line Input A
or
V-AMP LINK A
Example 2: 1-channel subwoofer application
Subwoofer with dual voice coil
A
Example 3: 1-channel subwoofer application
Subwoofer with dual voice coil in series connection
A
Input mode
(Input)
LED: Orange
A
Subwoofer
A
Subwoofer
Min. impedance
per speaker
Bridged: 4 Ω
Stereo: 2 Ω
VC 2 VC 1
VC = voice coil
! Min. impedance 2 x 2 Ω !
VC 2 VC 1
VC = voice coil
! Min. impedance 2 x 2 Ω !
This results in a min. total
impedance of 4 Ω
