10 | Technical data

Connection values
Class of protection
Beam angle (optics)
LED lifetime
Operating temperature
System of protection
Technical safety inspection
Colour rendering
LED-light
SYSTEMLED EVO Power 5700K
SYSTEMLED EVO Power 5700K
SYSTEMLED EVO Power 5700K
SYSTEMLED EVO Power 5700K
SYSTEMLED EVO Power 5700K
LED-light
SYSTEMLED EVO ECO 5700K
SYSTEMLED EVO ECO 5700K
SYSTEMLED EVO ECO 5700K
SYSTEMLED EVO ECO 5700K
SYSTEMLED EVO ECO 5700K
LED-light
SYSTEMLED EVO 4000K
SYSTEMLED EVO 4000K
SYSTEMLED EVO 4000K
SYSTEMLED EVO 4000K
SYSTEMLED EVO 4000K
14 | BA SYSTEMLED EVO . BA 11/2024
120-277V AC ± 10%, 50-60 Hz
I (protective grounding)
90°
> 100.000 h (L80/B10)
-10... +50 °C (14... 122 °F)
IP40
DIN EN 62471
R ≥ 90
a
Cascadable: The whole amperage of all chained lights may not exeed over the fuse
rating of the power supply system.
Product no.
155010-01
155110-01
155210-01
155310-01
155410-01
Product no.
155010-02
155110-02
155210-02
155310-02
155410-02
Product no.
155020-02
155120-02
155220-02
155320-02
155420-02
Lengh [A] Max. current
472 mm 0,9 A
898 mm 1,7 A
1120 mm 2,1 A
1342 mm 2,5 A
1782 mm 3,3 A
Lengh [A] Max. current
472 mm 0,5 A
898 mm 1,1 A
1120 mm 1,3 A
1342 mm 1,6 A
1782 mm 2,1 A
Lengh [A] Max. current
472 mm 0,5 A
898 mm 1,1 A
1120 mm 1,3 A
1342 mm 1,6 A
1782 mm 2,1 A
Max. power
consumption
~21 W
~41 W
~51 W
~60 W
~80 W
Max. power
consumption
~13 W
~26 W
~32 W
~38 W
~51 W
Max. power
consumption
~13 W
~26 W
~32 W
~38 W
~51 W
