6.4. Check whether the measuring capsule fits into the intended connection interface:
 S eatdepth29mm=LabellingMOC→followedby2.5
■
Seat depth 42 mm = Marking of connection interfaces MOC in existing pipelines.
■
For seat depth 42 mm, use the enclosed converter (Fig. 4). Remove small O-ring and insert the converter there.
Insert the small O-ring in the bottom of the converter.
6.5. Remove the L-sealing ring from the FMH and if necessary clean dirt away from the FMH, in particular of course on the
L-sealing ring's sealing surface.
6.6. Assemble the new measuring insert, as described in No. 1.4 to 1.12. Carefully check tightness and function.
6.7. Mark the connection interface with sticker MOC or MOE (see 2.4).
6.8. Mount the rosette.
7. Assembly key
To install and dismantle the measuring capsule meter, use the Installation-wrench.
8. User safeguard
A user safeguard (adhesive label, seal etc.) must be used to detect whether the measuring capsule has been removed from
the connection interface or to prevent an unauthorised removal.
9. Disposal
Battery-powered devices, or battery-powered modules additionally installed on mechanical devices, may contain
non-removable and non-rechargeable lithium batteries. These are marked with the WEEE directive symbol (crossed-out
garbage can). Batteries contain substances, which could harm the environment and might endanger human health if not
disposed of properly. To reduce the disposal quantity so as unavoidable pollutants from electrical and electronic equip-
ment in waste, old equipment should be reused prior or materials recycled or reused as another form. This is only pos-
sible if old equipment, batteries, other accessories and packaging of the products are returned to the manufacturer or
handed in at recycling centres. Our business processes generally provide that we or the specialist companies we use take
old devices including batteries, other accessories and packaging material back with us after they have been replaced or
at the end of their useful life and dispose of them properly.
Insofar as no other contractual arrangement has been made in this respect, your local or municipal authority or the local
waste disposal company can give you information relating the collection points for your used equipments. ZENNER will
always ensure correct disposal.
Attention!
Do not dispose of the devices with domestic waste. In this way, you will help to protect natural resources and to promote
the sustainable reuse of material resources.
Should you have any questions, please contact info@zenner.com
The latest information on this product and the current version of these instructions can be found at www.zenner.com
