WALL INSTALLATION

The Smart Sub 10 is designed for wall mounting, the necessary installation
material is included in the package To mount the Smart Sub 10 on the wall,
please proceed as follows:
Choose the desired position for installing your Smart Sub 10 and make
1
sure that no (electrical) cables or pipes (gas, water, heating, etc ) are
installed where the two mounting brackets shall be screwed into the
wall!
Attach the two mounting brackets to the wall with the angle facing
3
upwards Adjust one of the two mounting brackets in such a way that it
is in alignment with the second one
24
Drill two horizontally aligned holes at a distance
2
of approx 250mm to fix the mounting brackets
For wooden walls, pre-drill with a 3mm wood
drill bit For use of the dowels in stone/concrete
walls, drill holes with a 6mm stone drill bit, each
with a depth of min 30mm
