5 Audio-Visual Display
LCD Display (SC01/SC07/SC08)
While detecting CO, the LCD will display different indications to help you understand what to do, as shown below:
Mode LCD Display

LED Indicator

Powering On Runs through 8 cycles
(yellow/green/red) in
sequence.
Standby Mode Flashes green once
every 60 seconds.
Unit detected
Flashes red 3 times
smoke and every 4 seconds.
initiated an
alarm.
Unit
A CO concentration
detected CO
ranging from 50 to 999 ppm
and initiated has been present for a
an alarm.
certain time period. The
LED indicator flashes red
4 times every 5.8
seconds.
Alarm
Unit A CO concentration
Mode
detected CO
level ranging from 50
(alarm not
to 999 ppm has been
initiated). detected, but for less
than the allotted
detection period. The
LED indicator flashes
green once every 60
seconds.
Smoke - The LED indicator
concentra-
flashes green once
tion level
every second for 5
drops below seconds.
the alarm
threshold
Audible Remarks
Alarm
1 quick Make sure the alarm is
beep. properly attached to the
mounting bracket.
None. None.
3 long Dangerous smoke
beeps every concentration is detected. Open
4 seconds. nearby windows and doors, and
immediately move to fresh air.
4 quick Dangerous CO concentration
beeps is detected, and has reached
repeating the alarm status. Open nearby
every 5.8 windows and doors, and
seconds. immediately move to fresh air.
Note: This device also
triggers an alarm at CO
levels of 30–50 ppm.
None. Dangerous CO concentration
is detected, but has not
reached the alarm status.
Potentially dangerous CO
conditions exist.
Please search for the CO
source first. Open nearby
windows and doors, and
immediately move to fresh air.
Note: This device also triggers an
alarm at CO levels of 30–50 ppm.
None. Alarm cancellation: when
the smoke concentration
level drops below the
alarm threshold, the alarm
signal will stop. Then, the
alarm goes back to the
standby mode after testing.
12
CO
- The LED indicator
concentra-
flashes green once
tion level every second for 5
drops below
seconds.
the alarm
threshold.
2 sets of 3 red flashes
followed by 2 sets of 4
Test Mode
red flashes.
- Flashes red 3 times
every 4 seconds.
Flashes red 4 times
every 5.8 seconds.
Silence Mode
Flashes yellow once
every 60 seconds.
Flashes yellow 3 times
every 60 seconds.
Flashes green 3 times.
-
Flashes yellow once
Low Battery
every 60 seconds.
Flashes yellow 2 times
Fault
every 60 seconds.
None. Alarm cancellation: when the
CO concentration level drops
below the alarm threshold, the
alarm signal will stop. Then,
the alarm goes back to the
standby mode after testing.
2 sets of 3 Press the Test/Silence
long beeps button.
followed
by 2 sets of
4 quick
beeps.
None. Smoke silence mode: After
9 minutes, the unit will
exit silence mode.
None. CO silence mode: After 9
minutes, the unit will exit
silence mode.
None. Silence mode during low
battery: After 10 hours, the
unit will exit silence mode.
None. Silence mode during the end
of cycle: After 22 hours, the
unit will exit silence mode.
None. Exiting silence mode.
One beep Replace the unit
every 60 immediately.
seconds.
2 beeps Replace the unit
every 60 immediately.
seconds.
13
