VIEWEG
4 Commissioning
• Connect the power inlet cable to the Power inlet connector on the backside
• Connect the Air Inlet tube from the compressor to the Air Inlet at the backside of the
EN
VC 1200
• Connect the Foot switch (optional – Item no 504569) or the dispense cable of the
dispense robot to the Foot switch connector in the backside of the VC 1200
• Connect the spray air outlet to your spray valve and set the pressure for the spray air
via the pressure reducer on the front A typical value is approx 1 0 bar
• Connect the control air output to the control input of your spray valve
• Switch on the VC 1200 The display shows the initialisation and the installed
software version After 5 sec, the display switches automatically to the standard
screen and is ready for operation
• Check the pressure input (e g P-IN: 5 6 bar) in the display to be sure, that the air input
pressure is connected
Operating Manual Spray Valve Controller VC 1200
26
