GREEN: the clamp is fixed CORRECT.
RED: the clamp is
NOT
Only a proper fixing of BOTH TERMINALS ensures that the seat is secu-
red properly and offers full protection to your child in the car!!!
Please check once more, if the child car seat is securely fixed onto the
seat.
3.1. The child in the child seat
Place your child in the capsula® MT5 i-Fix child car seat. Let the shoulder strap of the
vehicle run through the belt guide slot. The shoulder strap should run in the middle of the
shoulder to ensure an optimal belt path.
Now run the lap belt (W) with the lock tongue (V) over the armrests of the child car seat
towards the three-point belt buckle and secure the lock tongue (V) from the three-point
belt of the vehicle into the three-point belt buckle with an audible << CLICK >>.
If necessary, use the vehicle's belt height adjuster to correspond to your child's height. The
lap belt must run as low as possible over the child's hips on both sides. Please check the
belt-run at least every six months and adjust the backrest to the new size of your growing
child. Make sure that the lap belt runs under the fixation lugs (C) on both sides and that
the diagonal belt leads only under the fixation lugs (C) on the side of the belt buckle (Q).
23
fixed CORRECTLY, please adjust
The diagonal belt should be centred over the child's shoulder, the lap belt should run as
low as possible over the groin. Make sure that the diagonal strap is straight and not too
close to the child's neck. All straps must be tight against the child's body and must not be
twisted.
Insert the diagonal belt into the belt holder until it is fully seated in the belt holder.Make
sure that the diagonal belt runs over your child's collarbone and does not lie against the
neck.
Tighten the vehicle belt by pulling the diagonal belt.
Before each journey, check that the seat belts are correctly seated and that the child
restraint system is correctly fastened.
ATTENTION! Never fasten the lap seatbelt differently, otherwise the child will not be held
properly.
3.2. Releasing the ISOFIX
Press the release button and release it from the vehicle's anchorage point. With an audib-
le >>CLICK<<< unlocks the ISOFIX anchorage. You can now remove the child seat.
4. Care and cleaning
4.1. Removing the cover
For the later correct installation we recommend to document the removal of the cover
with photos.
You can wash the cover with a mild detergent in the delicate wash program (30° C), plea-
se follow the instructions on the wash label. If you wash with more than 30°C the cover
can become discolored. Please wash the cover separately and do not tumble dry! Do
not dry the cover in the direct sun.
24
