Promac 378VTE Bedienungsanleitung Seite 5

4. Major Parts
Q P
O
N
M
L
K
J
A= Pulley Cover
B= Motor Handle
C= Switch cover
D=Tapping Sensor
E= Feed Handle
F= Table Lock
G=Table Handle
H= Displays current table-tilt angle
I= Floor Mounting Points
J= Base
K= Locks table rotation
L= Table
M= Chuck Guard
N= Spindle
O= Control panel
P= ON/OFF Switch
Q= Belt Tension Lock
