Endress+Hauser Proline t-mass 500 Beschreibung Seite 235

Proline t-mass 500 Modbus RS485
Navigation: Experte → Sensor → Messmodus → Zweites Gas
Parameter
Gasart wählen (3109)
Gas (3151)
Sondergasbezeichnung (3177)
Gaszusammensetzung (3110)
Mol% Air (3170)
Mol% Ar (3112)
Mol% C2H4 (3114)
Mol% C2H6 (3115)
Mol% C3H8 (3116)
Mol% CH4 (3117)
Mol% Cl2 (3118)
Mol% CO (3119)
Mol% CO2 (3120)
Mol% H2 (3121)
Endress+Hauser
Untermenü "Zweites Gas"
Register Datentyp
25261 Integer
25792 Integer
26997 ... 27004 String
25282 Integer
33126 ... 33127 Float
25298 ... 25299 Float
25888 ... 25889 Float
25896 ... 25897 Float
25904 ... 25905 Float
25912 ... 25913 Float
26205 ... 26206 Float
26213 ... 26214 Float
26221 ... 26222 Float
26229 ... 26230 Float
Modbus RS485-Register-Informationen
Zugriff Anzeige / Auswahl / Eingabe
Read / Write 2 = Gasgemisch
5 = Reines Gas
255 = Sondergas
Read / Write 0 = Luft
1 = Stickstoff N2
2 = Argon Ar
3 = Helium He
4 = Kohlendioxid CO2
5 = Sauerstoff O2
6 = Methan CH4
7 = Ammoniak NH3
9 = Wasserstoff H2
10 = Ethan C2H6
11 = Propan C3H8
12 = Butan C4H10
13 = Chlor Cl2
14 = Chlorwasserstoff HCl
15 = Kohlenmonoxid CO
18 = Hydrogensulfid H2S
21 = Ozon O3
23 = Ethylen C2H4
30 = Krypton Kr
31 = Neon Ne
32 = Xenon Xe
Read =
Read / Write 1 = Luft
2 = Wasserstoff H2
4 = Helium He
8 = Neon Ne
16 = Argon Ar
32 = Krypton Kr
64 = Xenon Xe
128 = Stickstoff N2
256 = Sauerstoff O2
512 = Chlor Cl2
1024 = Ammoniak NH3
2048 = Kohlenmonoxid CO
4096 = Kohlendioxid CO2
16384 = Hydrogensulfid H2S
32768 = Chlorwasserstoff HCl
65536 = Methan CH4
131072 = Ethan C2H6
262144 = Propan C3H8
524288 = Butan C4H10
1048576 = Ethylen C2H4
8388608 = Wasser
16777216 = Ozon O3
Read / Write 0 ... 100 %
Read / Write 0 ... 100 %
Read / Write 0 ... 100 %
Read / Write 0 ... 100 %
Read / Write 0 ... 100 %
Read / Write 0 ... 100 %
Read / Write 0 ... 100 %
Read / Write 0 ... 100 %
Read / Write 0 ... 100 %
Read / Write 0 ... 100 %
→ 
80
*
80
81
81
82
82
82
82
82
83
83
83
83
83
235
