EN

Using baby mask with angle

(optional accessory)
For the RF6 plus, there are various accessories for babies
and children. There are masks in different sizes and materials,
to provide each child a perfect inhalation therapy.
Please first check which masks fit your child best. The mask
should surround the mouth and nose
and lie tight on the children´s face. If your child cannot sit inde-
pendently, or you want to inhale while lying down, please use
the baby angle (D5).
• Plug in the nebulizer with the baby angle and mask, as seen
in the assembly diagram on page 4.
• Bring the baby / toddler into a relaxed position
• Align the position of the angle and the position of the mask
so that the nebulizer is always vertical. Otherwise medica-
tion could leak.
• For effective inhalation the mask should always be close
to the face, so that the child can inhale sufficient aerosol.
Therefore, apply the mask with light pressure over mouth
and nose.
• If the baby initially defends against inhalation, it is helpful to
directly take the mask in your hand (instead of the nebulizer),
so you can follow the head movements better.
12
Usage of our nebulizers in hospitals
with pressured air from the wall
Our nebulizers can be used in combination with inhalator-
compressors or Medical air-outlet in the wall. If you use the
wall-air-outlet we recommend to use a flowmeter to set the
flow. Depending on the used flow, you can set the following
values:
Air Output *
L/min. 9
(Compressor flow)
Max. pressure
1,8 ± 0,3
bar
compressor (e.g. MicroDrop Family2)
OPERATING PRESSURE** bar 0,70 ± 0,1
OPERATING FLOW
L/min. 4,2 ± 0,4
(Medical air from the wall)
Selector - Valve
MMAD (2) µm 3,34
Delivery Rate (ml/min) (1) ml/min' 0,19
Breathable fraction % < 5 µm 69,2 %
(1)Data shown is in accordance with Flaem Nuova internal procedure I29-P07.5. Values shown for the aerosol delivery may
vary depending on the patient's respiratory capacity.
(2) In vitro testing certified by TÜV Rheinland LGA Products GmbH - Germany in compliance with the European Standard EN
13544-1 for nebulizing systems. More details are available on request.
* messured at air outlet of compressor
** messured at the inlet of nebulizer
EN
10 14
2,6 ± 0,4 3,5 ± 0,5
(e.g. MicroDop Pro2) (e.g. MicroDrop Pro2 plus)
0,95 ± 0,1 1,30 ± 0,1
5,1 ± 0,3 6,0 ± 0,3
MAX Valve MAX Valve MAX
3,67 3,2 3,2 2,8 2,8
0,32 0,26 0,42 0,31 0,54
66,0 % 73,0 % 73,0 % 76,0 % 76,0 %
13
