Instructions For Use - Mpv Medical Microdrop Rf6 Plus Gebrauchsanweisung

EN

Instructions for use

Before each use, the nebulizer and accessories should be
cleaned according to the instructions in the section
"Cleaning, sanitization and disinfection" . This device is
intended to aerosolise drugs and solutions suitable for
inhalation treatment to be prescribed by the doctor. If the
drug or solution is too dense, dilution with suitable saline
solution might be needed, as prescribed by the doctor.
1. Insert the power cord of your compressor into a power
socket corresponding to the voltage of the device. This
must be positioned so that it is not difficult to discon-
nect it from the mains.
2. Open the nebulizer by turning the upper part (Pic. E1)
anticlockwise.
3. Pour the drug prescribed by the physician into the
lower part (Pic. F). Close the nebulizer by turning the
upper part (Pic. E1) clockwise. Make sure that the nozzle
(Pic. E3) is correctly seated in the upper part (Pic. E1).
4. Connect the accessories as shown in the "Assembly
diagram" (Pic. D). Sit comfortably, holding the nebulizer
in your hands, put the mouthpiece into your mouth or
use the mask.
5. If you use the face mask, fit it to the face as shown in
the picture (Pic. G).
6. Start the unit by means of switch (Pic. A2) and breathe in
and out deeply.
7. When the treatment is finished, turn off and unplug the unit.
8. It may happen that after a treatment session visible hu-
midity deposits form in the tube (Pic. D7): disconnect the
tube from the nebulizer and let it dry using the compressor
air flow, as this prevents mould from growing in the tube.
8
A personal use of the nebulizer and its accessories
is recommended in order to avoid any risks of infec-
tion. After every use, store the unit and the accesso-
ries in a dry and dust free place.
Pic. F
Pic. G
EN
9
