Sensor Configuration
Thesensorcan be configuredin two ways:
With keyson the sensor(basicsettings)
With the remotecontrol (completesetting options)
Configuration with keys
i 00
General procedure
I)
Keepk] and
pressedfor a correspondingength of time; every2 s the
greenLEDwill flash once
2)
Frequency of the flashinggreenLED (1-9times)indicates currentparameter
eve I
3) The parameterlevelcanbe decreased or increased with k] and
respectively
4)
Press[<]and
briefly to exit the programming mode(settingsare saved)
Changing the field size: Press
l,
small
92 4, 5,
medium
7,
arge
Changing the functionality: Press
forwards,mountinghe•ghtstandard
2
forwards,mountingheighthigh
3
backwards,mountingheightstandard
backwards,mouning heighthigh
4
5
direction recognitionOFF, mountingheight standard
6
direction recognitionOFF, mountingheight high
forwards+ MTO,mountingheightstandard(MTO,see chap
7
forwards+ MTO,mountingheight high(MTO,seechap 7)
8
Changing the field geometry:Press
narrow field
2*
wide fie d
Restore factory settings: Press
Example
Changing the functionalityfrom evel6 to evel 2:
I) Keep
and
pressedfor 4 s, the greenLEDblinksonceafter 2 s,
onceagain after 4 s
2) GreenLEDflashes6 timesand therebyindicatesthe current parameter eve
3) Press the key
fourtimes in a rowto decrease the parameterlevel
(greenLEDflashestwice and indicatesthe new parameter evel)
4) Press
and
at the same time
Note:
If no key is actuatedfor 25 s, the programming modeis automaticallyexited
howeverthe sensoris still in the configurationmode Thesettings madeup to
that point are saved
5.1.1
Statusquerywith keys
Thestatus queryis to find out what parametershavebeenset.
Parameter
Step 1
Press
briefly
Field size
Functionality
Press
briefly
Field geometry
Press
and
briefly at the sametime
6
and
for 2 s
and
for 4 s
7)
and
for 6 s
and [>] for 8 s
step 2
Frequency oftheflashing
green LED (1-9times) i ndicates
the currentparameterevel
Montageanleitung
5.2
Configuration with remotecontro
5.2.1
Sensoraddressing
8
Eachsensorcan be assignedan address(1*, 2, 3 or 4) Different addressesare
necessary when severalsensorsare within the rangeof a remotecontrol.
Mode of operation
5.2.2
R interface (infrared)
Numerical keysOto @
Control k eys @to (D
Start @
The datatransmissionto andfrom the sensoris ensuredby an Rinterface The
connectionbetweenthe remote controland the sensorcan on y be established
when the sensoris Inconfigurationmode
Configuration mode
Activation:
—Automatically after the sensoris connected to the supply
voltage or
—Briefly disconnect t he sensorfrom the supplyvotage or
-Press either key
Exiting:
—Press k ey
combinationor
—Automatically after 30 min
Establishing the connection
Without addressing:
1. Pressthe@start key
G and one of the keys 1 to 4 light up: Connection successfully established
— G flashes:
Connection
not established
-4 Activate configurationmode
Holdremote control closerto the sensorand point directly at it
Check batteries in remote control
— No keys light up
Check/rep ace batteriesin remotecontrol
Note:
If no entry is madefor 30 s, the connectionis ended The settings
madeup to that point are saved
Setting/ changingparameters
5.2.3
After the connectionhasbeensuccessful y established, t he parameters of the
sensorcanbe changed
0+0
Keepthe door openmanuallyfor 15 min when makingsettings
Afterwards,the door will close if no object is in the detectionarea
Doorcloseswhen no object is in the detectionarea,afterwards
standardoperation
Configuration modeis ended,door closeswhen no object is in the
detectionarea,afterwardsstandardoperation
GC 302 R
Address 1*
Address 2
Address 3
Address 4
ooo
or
on the sensor
With addressing:
1. Cover the IR Interface of the
remotecontrol with yourhand
2. Pressthe@start key —G) flashes
3. Release the IR interface
(remove hand)
4. Pressthe corresponding numerical
* Factory setting
123457 70705-9-9521 Ä-st.l
