SETTING UP THE SAW
Fig. 1 Assembling the blade
Fig. 2 Removing the blade
Fig. 3 Assembling the wheeled undercarriage
Fig. 4 Adjusting the blade guard position***
Fig. 5 Using dust extraction*
DUST SUPPRESSION**
Fig. 6 Residual Current Device (UK/EU 220-240V)
•
When plugging the saw in, the RCD will need to be reset before
the saw
will power on.
•
Plug the saw in, press the RESET button (c) on the RCD, there will
be a click.
•
The indicator window (b) will change to RED to show the power
is on.
•
To test, press the TEST button (a). Again, there will be a click and
the indicator window will switch to black showing the power is off.
Press the RESET button (c) again to reset and use the saw.
•
Note:
If the RCD trips during use, simply press RESET.
Note:
It is recommended that the machine should always be supplied,
via a RCD, with a rated residual current of 30MA or less.
Note:
If the indicator light shows red, a problem may exist, if unable to
reset after tripping, the RCD will need to be replaced immediately.
Fig. 7 Dust suppression for R300DCT+ and R350DCT models
Note: All R350DCT models are fitted with a manual AND electrical
valve eliminating the need to manually turn water off and on when
using the machine. When the manual valve is moved to the ON
position, (fig. 7.3) slight depression of the trigger (fig. 7.4) causes the
electrical valve to open allowing water to flow to the blade before the
motor is started with full depression of the trigger, it will remain open
until the trigger is released. The manual valve can also be used to
control the amount of water that is allowed to flow to the blade.
Fig. 8 Manual override of electrical valve
Note: For R350DCT models, if the electrical valve is damaged and
automatic water flow is not working, a manual override can be
performed. Use a screwdriver to remove the front panel of the
electrical valve to reveal the interal pipe. A screw is stored (Fig.8a)
which can be removed and screwed into the opening (Fig.8b) to
pierce the internal piping. This will allow water to flow through when
the valve is in the ON position. Please contact Evolution Power Tools to
request a repair for your tool.
PRE-CUTTING CHECKS
•
Ensure that the power supply matches the requirements
specified on the machines rating plate.
•
If an extension cable is required it must be of a suitable type
for the work environment. If used outdoors it should be
waterproof and so labelled.
•
The manufacturers instructions should be followed when
using an extension cable.
•
Route any extension cable so that it does not pose a trip
(or any other) hazard to the operator, colleagues or any
bystanders.
CUTTING
Fig.9 Cutting operation
WARNING: Ensure the workpiece is supported for stable
cutting. Allow the blade to reach maximum speed before starting
the cut. Cut smoothly and allow the blade to do the work without
forcing the blade.
WARNING: For R350DCT models, there is a LED light located
near the rear handle to indicate cutting pressure:
•
Solid green light: Cutting pressure is correct.
•
Solid red light: Too much pressure is being applied, operator
should ease off until the LED light shows green, the blade speed
will reduce if the saw is overworked.
•
Flashing red light: Increased pressure will stall the blade. User
will be required to remove the blade from the workpiece and
re-engage the trigger for the tool to reset.
WARNING: Do not attempt to cut curved or zig-zag lines.
Never use the side of the blade as a cutting surface. Never use to
perform inclination cutting.
MAINTENANCE
WARNING! Ensure the carbon brush slot is clear of dust
after multiple use. Risk of injury and/or tool failure may occur if
the brushes are not checked and cleaned regularly. To perform a
maintenance check -
1. Unplug the machine.
2. Remove the brush cap with a screwdriver and carefully remove the
carbon brush.
3. Clean the brush retainers and carbon brush with a dry brush.
4. Inspect the carbon brushes for any damage or burn marks, replace
with new items if necessary
5. Carefully blow away any dust.
6. Re-Install the carbon brushes while carefully sliding in the brush
retainers.
7. Re-attach the brush cap.
8. Operate the machine for a few minutes while idling.
Note: Risk of dust build up in the motor and other internal
parts can be minimised by running the machine after cutting.
Keep the motor running with no load applied with the blade
in free air, the airflow from the fan used to cool the motor will
blow any dust out of the vents at the front of the machine.
*Excludes R350DCT models.
**R300DCT+ and R350DCT models only.
***R300DCT, R300DCT+ and R350DCT models only.
