RF I/O SW...-4E(-BU)(-w/o|-2,2Ah) (SMA) (LBT)
Montage- und Anschlussanleitung / Funk-Universalsender
Mounting and wiring instructions / Wireless universal transmitter
Instructions de montage et de câblage / Emetteur universel sans fil
Istruzioni di montaggio e collegamento / Trasmettitore universale wireless
Instruções de montagem e instalação / Transmissor universal sem fio
Deutsch (Originalbetriebsanleitung)
Entsorgung
- Nationale, lokale und gesetzliche Bestimmungen zur
Entsorgung beachten.
- Materialien getrennt dem Recycling zuführen. Eventuell enthaltene
Batterien fachgerecht entsorgen.
ESD
Bei allen Arbeiten, die das Öffnen des Gerätes erforderlich machen,
auf ausreichenden ESD-Schutz achten.

Sicherheit

Das Gerät nicht in Verbindung mit Geräten benutzen, die direkt oder
indirekt gesundheits- oder lebenssichernden Zwecken dienen oder
durch deren Betrieb Gefahren für Menschen, Tiere oder Sachwerte
entstehen können.
Hinweise
Technische Änderungen vorbehalten. Umbauten und Veränderungen
am Gerät sind nicht gestattet.
English
Use of the mounting and wiring instructions
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer. In case
of doubt, the German language version of these instructions shall
prevail.
Scope of delivery
Device, battery*, mounting and wiring instructions, packaging.
* Battery not included in all versions. For more information, see the
»Battery« section.
Intended use
The device is used for radio transmission of switching information.
Mounting and wiring
Mount the device on an even surface. Teach in the device to operate as
described in the mounting and wiring instructions of the receiver.
Assignment of locations and radio frequencies:
Device type Radio frequency
SW868 868.3 MHz
SW915 915.0 MHz
SW917 917.0 MHz
SW922 916.5 MHz
External devices
The sensor/switch connection is led out at the four M12 connectors.
Connect the external devices to M12 (with connecting cable 1215497).
To connect external devices (sensors or switches): see section »Con-
necting external devices«.
When installing the external device, follow its installation instructions.
Connectable devices:
Device
0.3 m
RF IS M8 nb-ST
RF IS M12 nb-ST
RF IS M18 nb-ST
RF IS M30 nb-ST
RF RC 20 1S-ST 1335490
connecting cable,
open wire ends
Note:
- External switches must be suitable for the specified switching capac-
ity (3 V DC/0.3 mA at the moment of switch-on). The switching capac-
ity ensures a long battery life. Switches with gold contacts and reed
switches are suitable.
- Always use the specified connecting cable to connect external devic-
es. Only suitable for load-free external devices.
- In the event of a short circuit using the connecting cable 1215497, the
battery will discharge.
In this case: Replace the battery.
- When using external switches with the connecting cable 1215497,
note that the inputs are not galvanically isolated from each other.
Design of wireless range
The radio signal is attenuated on the way from the transmitter to the
receiver. In addition, the radio signal is influenced by obstacles. The
degree of attenuation depends on the material of the obstacle.
The following tables serve as a guide.
3 / 24
Location According to
EU 2014/53/EU (RED)
USA FCC
Canada IC
Mexico IFT
Brazil ANATEL
Japan ARIB STD-T108
Article no. (Cable length)
0.5 m 1 m 2 m
1470040 1373082 1305745
1228522 1356467 1189974
1261564 on request 1189975
1260490 1228548 1189976
1215497
