Solo CLEANLine 360-B Originalbetriebsanleitung Seite 10

5 Charging the battery
Using a conventional USB charger plug, with an
output voltage of 5.0V and a charging current
of ≤ 1.0A.
Battery charging temperature range: 0-40 ℃.
Charge the device before first use. For this,
connect the USB plug of the charging cable to a
USB power source of 5 V and the plug of the
charging cable to the connection socket (7) of the
battery-powered sprayer. The charging time is
1.5 h - 2 h. After that pull the charging cable out
of the connection socket (7).
6 Preparing the spray liquid and filling the
spray tank
Prepare the spray liquid according to the
instructions of the chemical manufacturer.
Only prepare dangerous spraying agent outdoors,
never inside any living rooms, stables or storage
rooms for food and feedstuffs.
To fill in the spraying liquid, open the tank screw
connection (4) by turning it anti-clockwise. Do not
use any tools for this!
Remove the entire spraying head (with the intake
tube (8) and filter with weight (9) from the
spraying agent tank.
Fill the tank up to the mark "1Ll" on the side of the
spraying agent tank.
Overfilling the tank or spills can contaminate
public waterways, rain- and storm water channel
and must be avoided.
Wipe off spilled spray liquid without delay.
After filling, insert the spraying head again and
screw it on tightly clockwise to prevent spraying
agent from escaping.
7 Application
Do not operate the battery-powered sprayer
without liquid. Running dry may damage the
device.
7.1 Spraying
Do not use the sprayer in wind or rain.
Check the direction of the air movement before
starting work and spray with the air movement,
not against it.
Hold the battery-powered sprayer by the hand
support (3).
Point the spraying nozzle at the target object from
a distance of approx. 50 cm.
Push the spray trigger button (2) to start spraying,
release the button to stop spraying.
ENGLISH 4
The spraying pattern can be set by turning the
spraying nozzle.
Turning anti-clockwise
produces a narrow, strong
jet.
Turning clockwise produces
a fine, scattered mist pattern.
When the spraying output clearly drops, the
battery needs to be recharged (see chap. 5)
7.2 Disposal of residual spray volume
Residual spray volumes of less than 20 ml
[0.68 oz] are no longer pumped effectively.
If you do not want to pour in any more spraying
agent and want to terminate spraying, collect
and dispose of the residual volumes in
compliance with the applicable laws and
provisions. Observe the specifications of the
spraying agent manufacturer.
At the end of the work, empty and clean the
sprayer according to chap. 8.1, wash face and
hands thoroughly and take off the work
clothing. Work clothing requires regular
washing.
8 Cleaning and storage
8.1 Emptying and cleaning the spraying
agent tank
Empty the spraying agent tank every day after
use. Collect and dispose of the residual amount
of the spraying agents in accordance with
applicable laws and provisions. Observe the
information from the spraying agent
manufacturer. Flush the spraying agent tank
well with clean water. Run the battery-powered
sprayer once again with clear water.
Let the spraying agent tank dry while open after
cleaning.
8.2 Down periods and storage
Empty and clean the sprayer according to
chap. 8.1.
Keep the sprayer protected from sunlight in a
dry, frost-free and secure location at a
temperature of max. 35 °C [95 °F].
No open fireplaces or similar must be nearby.
Prevent unauthorised use – especially by
children.
