Rear Shower / Lady Shower; Water Volume Adjustment; Nozzle Position Adjustment; Stop Cleaning Function - Laufen Cleanet Pro Lite Bedienungsanleitung

4 OPERATING THE SHOWER TOILET
4.1 REAR SHOWER
To activate rear wash, press 0,5sec (1 beep) the rotary control button and
release.
×0.5sec
LADY SHOWER
To activate lady wash, press 2sec (2 beeps) the rotary control button and
release.
×2sec

WATER VOLUME ADJUSTMENT

4.1.1
While you are using the rear shower or lady shower functions, turn the rotary
control button clockwise and counterclockwise for setting the water flow.
For each position, forward or back, a beep will be heard (if silent mode is not
activated). When maximum or minimum position is reached a double beep will
be heard.
Turn the controller
forwards to increase the
jet intensity.
If you wish to shower again, press the controller while the shower arm is retracting at the end
of the first showering procedure.
The factory setting for the water temperature is level 3.
The shower duration is factory preset to 2 minutes. It can be changed using Smart Control
APP.
Improper operation includes initiating the shower procedure without anyone sitting on the
shower toilet.
This may cause water damage in the surrounding area.
4.1.2

NOZZLE POSITION ADJUSTMENT

While you are using front shower or rear shower functions, press and turn the
rotary control button clockwise to move the shower jet forwards.
Press and turn the rotary control button anti-clockwise simultaneously to
move the shower jet back.
For each position clockwise or anti-clockwise, a beep will be heard. (if silent
mode is not activated).
When maximum or minimum position is reached a double beep will be heard.
Press the controller and
simultaneously turn it
forwards to move the
shower jet forwards.

STOP CLEANING FUNCTION

4.1.3
To stop wash function, press the rotary control button during shower.
×1
Turn the controller backwards
to reduce the jet intensity.
Press the controller and
simultaneously turn it back to
move the shower jet back.
9
