Tab. 7:
Connection cable
assignment
Technical data
Cable colour Title
Grey Trip latch
Brown
Blue Left handle
Green
Purple Bolt contact
Black
White
Pink Right handle
Red
Red/blue Cylinder contact
Yellow
Grey/pink
Contact Plug PIN
COM 9
NO 4
COM 5
NO 2
COM 8
NC 1
NO 6
COM 7
NO 3
COM 10
NC 11
NO 12
Comment/function
Trip latch status (with external door
contact switched in series)
Flip latch extended:
COM NO open
Flip latch retracted:
COM NO closed
Handle not actuated:
COM NO open
Handle actuated by 10%:
COM NO closed
Bolt extended to 95%:
COM NO closed
Bolt retracted:
COM NC closed
Handle contact:
COM NO closed
Tampering: DIP = ON
Factory setting: DIP = OFF (switcha-
ble cover plate opening on lock)
COM NO closed as long as cylinder
is moved but only until bolt contact
switches
