2 - INTRODUCING THE PRODUCT
2.1 - Description of the product
The gear motor SUN is intended to be installed within systems for
the automation of sliding gates. The SUN gear motors have been
designed to automate sliding gates within the weight limits indicated
2.2 - Model and technical characteristics
CODE
DESCRIPTION
SUN5024
SUN5324
SUN5024F
SUN7024
SUN7324
SUN11024
SUN11324
TECHNICAL DATA
MODELS
Speed*
Torque
cycles /
Working cycle**
Control unit
Power supply
automation
Frequency
Motor power supply
Output power
Integrated lights
Degree of
protection
Operating
temperature
Leaves max weight
Sound emission level
Dimensions (L-P-H)
Package dimensions
Package weight
* Variable data according to gate weight
** Cycles/hour referring to a standard leaf with a length of 4m and
weight of 200Kg, evaluated at an ambient temperature of 20°C.
For leaves longer than 4m the maximum number of cycles/hour
must be reduced proportionally (for example, for 8m leaves the ma-
ximum number of cycles/hour must be reduced by 50%).
For environmental temperatures above 20°C the maximum number
of cycles/hour will be reduced by 15% for every 5°C increase in
4
24 Vdc gearmotor with mechanical limit switches and lights, gate up to 500 kg, residential use.
24 Vdc gearmotor with mechanical limit switches, gate up to 500 kg, residential use.
24 Vac gearmotor with magnetic limit switches and lights, gate up to 500 kg, intensive use, fast.
24 Vdc gearmotor with mechanical limit switches and lights, gate up to 700 kg, intensive use.
24 Vdc gearmotor with mechanical limit switches, gate up to 700 kg, intensive use.
24 Vdc gearmotor with mechanical limit switches and lights, gate up to 1100 kg, intensive use.
24 Vdc gearmotor with mechanical limit switches, gate up to 1100 kg, intensive use.
SUN5024
SUN5324
cm/s
26
Nm
18
40
hour *
14A
CT10324
Vac
Hz
Vdc
W
250
250
YES
NO
IP
°C
500
500
kg
dB(A)
mm
mm
12,5
12,5
kg
in the technical specifications table.
The use of gear motors for applications which differ from those
indicated above is prohibited.
SUN5024F
SUN7024
26
40
18
23
40
40
14AF
50/60
300
YES
YES
-20 +55
500
≤ 70
330 - 255 - 400
340 - 255 - 400
14
13,5
temperature (for example, for an environmental temperature of
30°C the maximum number of cycles/hour will be reduced by
30%).
For doors whose weight corresponds to the maximum use limit for
that type of product, the maximum number of cycles/hour will be
reduced by 50%.
SUN7324
SUN11024
25
25
26
26
40
40
14A
CT10324
230
24
345
345
NO
44
700
700
13,5
SUN11324
20
20
38
38
50
50
14A
CT10324
360
360
YES
NO
1100
1100
14,5
14,5
