BSS-Streaming Service
Technical specifications
Conditions for proper use
Temperature range
Relative humidity
Storage temperature
Do not use at altitudes over
2000m above sea level
Do not operate in a dusty
environment
Electrical connected load
Supply voltage
~230V/6,67A
Power
Electrical connection values battery voltage
Supply voltage
= 12 - 14,4V/5A
Power
Maximum screw tightening torques
Description
Screw size
ATEM-Cover
DIN 7380 M4x12
ATEM C-clamps
ISO 7380 M3x8
Page 50
+5° – +40° C
20 – 90%
No condensation
-20° – +60° C
Rodecaster Video Case
80 W
Rodecaster Video Case
60 W
Maximum torque
0,3 Nm
0,2 Nm
BSS-Case
Operating instruction EN
Troubleshooting
Occurred error
The built-in components
do not work.
With battery operation
- the built-in components
do not work
The screen doesn't work.
The fan is not running
A connected device is not
recognized on the ATEM
Mini / Extreme.
First action
Further action
Check if the power plug is
Turn on the on/off switch
plugged in properly.
on the BSS case again.
Check whether mains
Plug into a different outlet/
voltage is present.
circuit.
Check for battery voltage. (is
Remove all connected
the LED on the front lit?)
consumers (e.g. at the USB
port) and turn the on/off
switch on again.
Turn on the screen by
Check that the 12V DC
pressing the power button
power connector on the
(top right) for >5 seconds.
screen (bottom left) is
properly plugged in.
Switch off the BSS case,
Carefully remove the
disconnect it from the power
foreign body from the
supply and check whether a
outside. Otherwise contact
foreign object is blocking the
our service.
fan (visual inspection).
Ensure that the appropriate
For HDMI input signals:
interface on the device is
Change the HDMI input on
enabled and compatible with
the BSS case and/or swap
the required ATEM input
the HDMI connection cable.
values.
DOC-000063
DE
EN
FR
IT
ES
Page 51
