Routine Maintenance
D
Note: The frequency of replacement may vary with the
actual situation. If abnormal wear occurs, replace the
parts immediately.
Main Brushes
D1
* Clean every 2 weeks and replace every 6-12 months.
D1-1—Hair-Blocking Rings
D1-2—Main Brush Caps
D1-3—Main Brush Cover
D1-4—Main Brush Cover Latches
D1-5—Main Brush Bearing
D1-6—Main Brushes
D1-7—Turn over the robot and press the
main brush cover latches to remove
the main brush cover.
D1-8—Pull out the main brushes and
remove the main brush bearings,
main brush caps, and hair-blocking
rings. Remove any entangled hair
or dirt at both ends of the main
brushes. Then, reinstall the hair
blocking rings, main brush caps, and
main brush bearings.
D1-9—Reinstall the main brushes. Firmly snap
the main brush bearings into place.
Only after the bearings are securely
installed, fit the main brush cover.
D1-10— Reinstall the main brush cover. Make
sure its four teeth are fully seated in
the slots, and press the main brush
cover latches until you hear it lock
with a click. Then, lift the main brush
cover by each side to check whether
it is securely installed.
Notes:
• To securely install the main brush cover, make sure
to press both of the red main brush cover latches in
place.
• Main brushes should be wiped down with a wet cloth. If
the main brushes are wet, air-dry them away from direct
sunlight.
• Do not use corrosive cleaning fluids or disinfectants to
clean the main brushes.
• To prevent injury caused by blades used to cut hair
inside the main brush cover, make sure to install two
main brushes in place before installing the main brush
cover.
• To prevent injury caused by blades inside both ends
of the main brush cover, when the main brush cover
is in place, keep your body or pets away from main
brushes.
Flexible Side Brush
D2
* Clean monthly and replace every 3-6 months.
Unscrew the side brush screw. Remove and
clean the side brush. Reinstall the brush and
tighten the screw.
Omnidirectional Wheel
D3
* Clean as required.
D3-1—Use a tool, such as a small screwdriver,
to pry out the axle and take out the wheel.
Note: The omnidirectional wheel bracket cannot be removed.
D3-2—Rinse the wheel and the axle with
water to remove any hair and dirt.
Air-dry, reinstall, and press the wheel
and axle back in place.
09
Main Wheels
D4
* Clean as required.
Clean the main wheels with a soft, dry cloth.
Dustbin
D5
* Clean as required.
D5-1—Remove the magnetic top cover of
the robot and press the dustbin latch
to take out the dustbin.
D5-2—Remove the filter cover, press the
filter latch to uninstall the washable
filter, and then empty the dustbin.
D5-3—Fill the dustbin with clean water and
reinstall the washable filter. Gently
shake the dustbin, and then pour out
the dirty water.
Note: To prevent blockage, only use clean water without
any cleaning liquid.
D5-4—Allow at least 24 hours for the dustbin,
filter cover, and the filter to dry
thoroughly before reinstalling them.
Washable Filter
D6
* Clean every 2 weeks and replace every 6-12 months.
D6-1—Uninstall the filter cover and the
washable filter.
D6-2—Rinse the filter repeatedly and tap it
to remove as much dirt as possible.
Note: Do not touch the surface of the filter with hands,
brushes, or hard objects to avoid potential damage.
D6-3—Allow at least 24 hours for the filter to
dry thoroughly before reinstalling it.
