Mop Cloths
D7
* Clean as required and replace every 1-3 months.
D7-1—Remove the mop cloths from the
mop cloth mounts. Clean the mop
cloths and air-dry them.
Note: A dirty mop cloth will affect the mopping
performance. Clean it before use.
D7-2—Stick the mop cloths on the mounts
flat in place.
Robot Sensors
D8
* Clean as required.
Use a soft, dry cloth to wipe and clean all
sensors, including:
D8-1—Dock Locator
D8-2—Reactive AI Obstacle Recognition
Sensor
D8-3—Wall Sensor
D8-4—Communication Sensor
D8-5—Carpet Sensor
D8-6—Five Cliff Sensors
Moving Dock
D9
To move the dock, grip the cord storage slot
on the back with one hand and the inner
side of the front board with the other hand.
Do not move the dock by lifting the dock base,
water tank handles or dust container cover
directly to prevent the dock from falling off.
Dirty Water Tank
D10
* Clean as required.
Open the dirty water tank lid and pour out
the dirty water. Fill the tank with clean water,
close the lid, and shake. Pour out the dirty
water. Lock the lid and reinstall the tank.
Notes:
• To avoid deformation, only use cold water.
• If any water stains remain on the outside of the
water tank, wipe them with a soft, dry cloth before
reinstalling the tank.
Charging Contacts
D11
* Clean as required.
Use a soft, dry cloth to wipe the charging
contacts on the robot and the dock.
Replacing Disposable Dust Bag
D12
* Replace as required.
D12-1—Remove the dust container cover.
D12-2—Remove the disposable dust bag in the
direction of the arrow as shown and
discard it.
Notes:
• The dust bag handle seals the bag on removal to
prevent leakage.
• Always install a dust bag before reinstalling the dust
container cover to avoid auto-emptying without the
bag. You can also disable auto-emptying in the app.
D12-3—Clean around the filter with a dry
cloth. Install a new disposable dust
bag in place along the slot and
unfold the dust bag to maximize
emptying performance.
10
Note: Make sure the disposable dust bag is properly
installed to avoid waste escaping and damaging the
dock.
D12-4—Reinstall the dust container cover
in place to make sure the dust
container is securely sealed.
Cleaning Tank Module
D13
* Clean as required.
D13-1—Remove the cleaning tank module.
D13-2—Remove the cleaning tank and filter
from the module and then rinse
them with water.
D13-3—Reinstall the filter and cleaning tank.
Then, reinstall the cleaning tank
module.
