A10-15—Filter
A10-16—Dock Location Beacon
A10-17—Clean Water Dispensers
A10-18—Water Level Float
A10-19—Drying Air Outlets
Power Cord Storage
A11
A11-1—Cord Outlets
A11-2—Power Port
A11-3—Cord Storage Slot
Installation
B
Important Information
B1
B1-1—Tidy cords, hard or sharp objects
(such as nails and glass), and loose
items from the ground and move
any unstable, fragile, precious, or
dangerous items to prevent personal
injury or property damage due to
items becoming tangled in, struck by,
or knocked over by the robot.
B1-2—When using the robot in a raised
area, always use a physical security
barrier to prevent accidental falls
that may result in personal injury or
property damage.
Notes:
• When using the robot for the first time, follow it
throughout its whole cleaning route and watch for
potential problems. The robot will be able to clean by
itself in future uses.
• To prevent excessive buildup of dirt on the mop cloths,
floors should be vacuumed at least three times before
the first mopping cycle.
Assembly
B2
B2-1—Place the dock on a hard, flat floor
(wood/tile/concrete etc.), flat against
a wall. Attach the base by pressing
down both sides of the base firmly,
and then pressing the connecting
part in the middle until you hear a
click.
B2-2—Click
Note: When moving the dock, secure the water tanks to
prevent it from falling off.
B2-3—Connect the power cord to the back
of the dock, and keep the excess
cord inside the storage slot.
Note: Power cord can exit at either side.
B2-4—Align and install the mop axles into
the robot in place until you hear a click.
B2-5—Click
Positioning the Dock
B3
Reserve a space of about 0.9 m (2.9 ft) in
height, 0.4 m (1.3 ft) in length and 1.2 m (3.9
ft) in width. Make sure that the location has
good WiFi access for a better experience
with the mobile app. Plug in and make sure
that the status indicator light is on.
B3-1—About 0.9 m (2.9 ft)
B3-2—About 0.4 m (1.3 ft)
B3-3—About 1.2 m (3.9 ft)
Notes:
• If the power cord hangs vertically to the ground, it
may be caught by the robot, causing the dock to be
06
moved or disconnected.
• The dock status indicator light is on when the dock is
powered on, and off when the robot is charging.
• The dock status indicator light turns red if an error occurs.
• Place the dock on a flat floor away from fire, heat, and
water. Avoid narrow spaces or locations where the robot
may be suspended in the air.
• Placing the dock on a soft surface (carpet/mat) may
cause the dock to tilt and cause docking and departing
problems.
• Keep the dock away from direct sunlight or anything
that may block the dock location beacon, otherwise
the robot may fail to return to the dock.
• Do not use the dock without clean water tank, dirty
water tank, dust container cover, disposable dust bag,
or cleaning tank module.
• Maintain the dock according to the Routine Maintenance.
Do not clean the dock power cord and charging contacts
with a wet cloth or tissue.
• All docks are subject to water-based tests before
leaving the factory. It is normal that a small amount of
water remains in the waterway of the dock.
Powering On & Charging
B4
Press and hold the button to power on the
robot. Wait until the power indicator light is
steady, and then place the robot in front of
the dock. Make sure the dock is plugged in.
Then, press the button and the robot will
automatically return to the dock for charging.
The robot is equipped with a built-in high-
performance lithium-ion rechargeable battery
pack. To maintain battery performance, keep
the robot charged.
B4-1—Dock status indicator light off, robot
power indicator light breathing:
Charging
Note: The robot may not be turned on when the battery
is low. In this case, place the robot to the dock for
charging.
