3. Use a suitable solvent to remove any lime deposits on the quartz glass (5). Rinse thoroughly
before installation.
4. Check the quartz glass for damage. A defective quartz glass must always be replaced.
Fit everything in reverse order.
Make sure that the red O-ring (6) is properly seated in the corresponding groove in the housing
and the black O-ring (4) in the quartz glass socket. Grease the O-rings with Vaseline if required.
Push the quartz glass completely into the housing of the lamp. Check that the protective cap (3).is
fitted onto the tube Push the lamp socket with the UVC tube carefully into the quartz glass and
tighten the socket firmly by hand.
Replacing the UVC tube:
1.Always switch off the power supply by pulling the mains plug before maintenance work.
2.Unscrew the bulb socket (1) of the lamp housing, remove the UVC tube (2) and replace the old
tube with a new one. Fit everything in reverse order (see above) and be sure that the O-rings are
correctly fitted. Grease the O-rings with Vaseline if required.
Caution! Do not touch UVC tube (2) directly with your hand; put on cotton gloves!
Old UV-C tubes shall not get broken and must not be disposed in regular garbage bin. Contact
your local waste disposal company. Do not use an sharp edged tools. In case Quartz glass
cylinder or O-ring are defect, they should get replaced immediately.
Function check of UVC lamp
You can check the function of the UV-C tube by a bluish shimmer on the sight glass (16) of the UV-
C lamp.. This check works best in low light.
Please note that you can only carry out the function check when the UV-C lamp is completely
assembled, as it has a protective circuit that prevents UV radiation from being emitted outside the
housing. If the UV-C tube does not burn, the UV-C lamp may not have been assembled correctly.
Check this using the installation instructions above.
Winter - maintenance
• Protect your UVC tube from freezing!
• Completely clean the UVC tube as specified in the instructions.
• Store the UVC tube over winter in a frost-free location.
7. Warranty
The present device was manufactured and inspected according to the latest methods. The seller
warrants for faultless material and workmanship in accordance with the legal regulations of the
country in which the device was purchased. The warranty period begins with the day of the
purchase and is subject to the provisions below:
Within the period of warranty, all defects which are to be attributable to defective materials or
manufacturing will be eliminated free of charge. Any complaints are to be reported immediately
upon their detection.
The warranty claim becomes void in the case of interventions undertaken by the purchaser or by
third parties. Damage resulting from improper handling or operation, incorrect setting-up or
storage, inappropriate connection or installation or Acts of God or other external influences are
excluded from warranty.
Parts subject to wear, such as the UV–C tube, rotor and bearings are excepted from the
guarantee. All parts were manufactured using maximum care and high-quality materials and are
designed for a long lifecycle. It should be understood, however, that the wear and tear depends on
the kind of use, the intensity of use and the internals of maintenance. Complying with the
installation and maintenance information contained in the present operating instructions will
therefore considerably contribute to a long lifecycle of these wearing parts.
In case of complaints, we reserve the option of repairing or replacing the defective parts or replace
the entire device. Replaced parts will pass into our property.
