Exsys EX-60121 Anleitung

CONNECTORS & LEDs
RJ45 Port:
RJ45 Port
Pin Signal Pin
1 BI_DA+ 4 BI_DC+
2 BI_DA- 5 BI_DC-
87654321
3 BI_DB+ 6 BI_DB-
SATA connector:
Pin Description Pin Description
1 3.3V (orange) 6 ground (black)
2 3.3V (orange) 7 5V (pre-charge)
3 3.3V (pre-charge) 8 5V (red)
4 ground (black) 9 5V (red)
5 ground (black) 10 ground (black)
If no SATA cable is connected, PoE power is supplied via the PCIe bus. If the computer does not
have sufficient power on the PCIe bus, PoE power can be supplied via the 15-pin SATA connector.
Caution!
Never connect or disconnect the connector while the PC is switched on!
Status LEDs:
LED Name Color
Green Green:
Speed
Yellow Yellow:
Steady on: Connected
LINK (ACT) Green
Blinking:
Steady on: PoE (PD) device connected
PoE Speed Green
Off:
5
HARDWARE INSTALLATION
Please note the following installation instructions. As there are major differences between PCs, we
can only provide you with general instructions for installing the EX-60121. If in doubt, please consult
the manual for your computer system.
Signal Pin Signal
1. Switch off your computer and all connected peripheral devices and unplug all devices from the
7 BI_DD+
mains.
8 BI_DD-
2. Loosen the housing screws on the back of your computer and carefully pull off the housing.
3. Now locate a free PCI Express slot (x4 or larger) and carefully insert the card into the selected
PCI Express slot. Make sure that the card is seated correctly and that there is no short circuit.
4. Then secure the card to the housing with a screw.
5. Now close the computer housing with the previously removed screws.
DRIVER INSTALLATION
Pin Description
11 reserved
Windows / Linux / Unix
12 ground (black)
Once the hardware installation is complete, the operating system will automatically detect and
install the card. If the drivers are not installed automatically, they can be downloaded from the
13 12V (pre-charge)
EXSYS website (www.exsys.de / www.exsys.ch). Enter the article number in the search field
and select the appropriate article. Under 'Downloads' you will find the current driver as a ZIP
14 12V (yellow)
file. Once you have extracted the driver folder to your computer, run 'Autorun.exe'. Follow the
installation instructions to complete the installation.
15 12V (yellow)
Important! Reboot your PC/Server after installation.
CHECK INSTALLED DRIVER
Open the >Device manager<. Now you should see at „Network adapters" the following new
entries:
If you see these or a similar informations the device is installed correctly.
LED Function
10Gbps
10/100/1000Mbps, 2.5/5Gbps
data transmission
no PD device detected
Germany:
EXSYS Vertriebs GmbH
Industriestrasse 8
61449 Steinbach
www.exsys.de
Switzerland: Italy:
EXSYS Vertriebs GmbH EXSYS Italia Srl
Dübendorfstrasse 17 Via Belvedere, 45/B
8602 Wangen I-22100 Como
www.exsys.ch www.exsys.it
6
Anleitung
Vers. 1.0 / 15.01.25
AUFBAU
Status LEDs
2x RJ45 Port
BESCHREIBUNG & TECHNISCHE DATEN
Die EX-60121 ist eine 10 Gigabit Ethernet Karte einem RJ45 Port und Power over Ethernet
(PoE) für den PCIe Bus. Sie unterstützt Half- und Full-Duplex sowie Auto-Negotiation zur
automatischen Anpassung an die Geschwindigkeit im Netzwerk (10/100/1000/10000 Mbit/s).
Dank der integrierten PoE-Funktionalität können angeschlossene PoE (PD) Endgeräte (IP-
Telefone, IP-Kameras etc.) über das Netzwerkkabel mit Strom versorgt werden. Die EX-60121
unterstützt die PoE-Standards IEEE 802.3af (PoE), IEEE 802.3at (PoE+) und ermöglicht eine
maximale Leistungsabgabe von bis zu 30 W.
Kompatibilität: PCI-Express x2 bis x16
Betriebssysteme: Windows 8.x/10/11 (32/64 bit), Linux ab 3.10
Anschlüsse: 1x RJ45 Gigabit Ethernet Anschluss
Lieferumfang: EX-60121, Low Profile Bügel, Anleitung
1
EX-60121
