4.6.1 laying the cables

Fig. 19: Laying the cables

4.6.2 Mounting the TV wall mount covers

Tools for all Models
Fig. 20: Mounting the TV wall mount covers

4.6.3 Mounting the covers

Fig. 21: Mounting the covers
End of installing. To remove, proceed in reversed order.
32
1. Use sufficient long cables.
2. Lay them along the swivel arms.
3. U se tape for fixing.
Leave enough slack in the cables to ensure
mobility of the system
1. Cut the edges on the lower side of
the TV wall mount covers at the
breaking points for laying the
cables.
Attend to the different part names of models
51884/51894 and 51885/51895.
2. Plug the TV wall mount covers
laterally from right and left onto the
TV wall mount (A).
1. Plug the covers laterally from right
and left onto the TV wall mount (A).
Attend to the different part names and
scope of delivery of models 51884/51894
and 51885/51895.
