4.5

Hanging in and Fixing VEsa plate and Flat screen

Tab. 22: Hanging in and Fixing VESA plate and Flat screen
Tools for all Models
Fig. 17: Hanging in and Fixing VESA plate and Flat screen 51884/51894
Fig. 18: Hanging in and Fixing VESA plate and Flat screen 51885/51895
4.6

laying the cables and attaching the covers

Tab. 23: Laying the cables and attaching the covers
Risk of injury by tripping and falling
>> Place, transport and install product, parts
and acceories in a safe way.
>> When working with burdens, secure your-
self and the working place, let a second
person help you.
Risk of material damage by inappropri-
ate ambient conditions
>> Keep enough space around product and
to the whole system to ensure proper
ventilation and mobility.
1.
2.
Attend to the different part names of models
51884/51894 and 51885/51895.
Risk of material damage by inappropria-
te ambient conditions
>> Keep enough space around product and to
the whole system to ensure proper ventilati-
on and mobility.
A ssemble the preassembled flat
screen and VESA plate (B) together
with a second person to the TV wall
m ount (A), like shown.
Fix the connection by the mounting
material like shown.
31
