Troubleshooting - Carson X-10NB Chassis Betriebsanleitung

j. Troubleshooting
Please read this in the event of a problem.
Engine won't start.
Engine flooded. Remove glow plug. Pull pull-start 6-8 times.
Too much fuel in
Beware of spraying fuel.
engine
Dead glow plug Remove glow plug. Place glow plug in heater.
heater If the glow plug does not glow orange the plug
maybe dead.
Dead glow Place new glow plug in heater. If it glows dim or
heater battery not at all, replace heater battery.
Engine Stalls
Overheating Check temperature. If over 130, richen carb
mixture. Check to make sure wheels spin freely.
Disconnected Reattach pressure line from exhaust pipe to fuel
fuel pressure tank lid.
line
Hard to control, glitching
Dead/weak Batteries in transmitter should be fully charged.
batteries Slow servos mean dead receiver batteries.
Improper Refer to instructions on setting up your
transmitter transmitter.
settings
Model doesn´t Transmitter or chassis power switch is not "ON".
move
Polarity or battery type is wrong.
Batteries have run down.
Empty fuel Fill fuel tank. Prime engine by pulling pull-start
tank/ No fuel in once while holding finger tip over muffler (Wear
engine gloves).
Overheating Running at high temperatures may cause vapour
lock. Let the car cool down for 10-15 minutes
Dirty air Wash with soap and water or glowfuel then use
cleaner air filter oil.
Carburettor Check carb-lock bolt and nut. Press carb onto
loose engine block, tighten nut to prevent air leak.
Doesn´t run Steering trim is not adjusted correctly.
straight
Front and rear wheel nuts are too loose.
Doesn´t stop Throttle trim is not adjusted correctly.
Running too Motor has lost power.
slowly
Rear wheel nuts are too loose.
Dust or foreign objects are inside gears.
CARSON X10NB Chassis
GB
23
