b. Chassis
GB
Fuel-tank
Muffler
Front tyre
Chassis
Front shock unit
c. Plug in Receiver Batterie
Make sure positive (+) and negative (-) ends are facing the correct
direction. Then plug the pack into the switch harness, inside the radio
case. Black goes to black and red goes to red. Replace the radio case
cover.
Racer Tip:
Use rechargeable batteries! Use our NiMh 6 V/ 1100 mAh battery pack
(500608104).
18
CARSON X10NB Chassis
Motor
Air filter
Picture 1
Wing
Receiver box
Rear tyre
Throttle servo
Steering servo
Rear shock
unit
