Epropulsion SPIRIT 1.0 Plus Bedienungsanleitung Seite 10

1.3 Specifications
SPIRIT 1.0 Plus-L/ SPIRIT 1.0 Plus-S / SPIRIT 1.0 Plus-XS
Type
Input Power
Equivalent Power
Max Overall Efficiency
Rated Rotation Speed
Control System
Weight (without battery)
Dimension (L×W×H)
Shaft Length
Trim Angles
Tilt Angle
Propeller (Diameter × Pitch) 11" × 5.8" 2-blade composite propeller
Electric Outboard Motor
1 kW
3 hp
55%
1200 rpm
Integrated Tiller
10.4 kg / 22.9 lbs. (XS)
10.6 kg / 23.4 lbs. (S)
10.8 kg / 23.8 lbs. (L)
880 × 273 × 1010 mm / 34.6 × 10.7 × 39.8 inches (XS)
880 × 273 × 1110 mm / 34.6 × 10.7 × 43.7 inches (S)
880 × 273 × 1235 mm / 34.6 × 10.7 × 48.6 inches (L)
525 mm / 20.7 inches (XS)
625 mm / 24.6 inches (S)
750 mm / 29.5 inches (L)
manual, 0°, 7°, 14°, 21°
manual, 70°
8
