Step 3: Connect to Solar Panels
• Never connect the leads of a solar panel to different PV terminals (e.g., negative to PV1− and positive to
PV2+) to prevent short circuits.
A2
×8 / ×6
A2
Step 4: Connect to Load / Microinverter (Optional)
• Connect a microinverter that complies with local regulations to add power input. EcoFlow microinverters are
preferred; third-party models may require users to take additional measures.
• The device has an IP65 ingress protection rating. Use of the AC outlet may affect the ingress protection rating.
To minimize exposure to water, place the device close to a wall.
• Ensure the AC outlet cover remains in place when the AC outlet is not being used.
• The actual appearance of the AC outlet may vary by sales region and product version.
8 |
Appliances
• Keep unused terminals covered
with their protective caps.
• If you need to adjust the PV
connection, disconnect the solar
connectors using the PV wrench.
Microinverter
A4
