1
1- Decrease timer
2- Timer display
3- Timer zone indicator
4- Timer selection
5- Increase timer
Use the induction cooking zones with
suitable cookware.
After mains voltage is applied, the hob
is in the stand-by mode and is ready for
operation.
The hob is controlled by the use of knobs
for setting the cooking level and touch
sensors for setting the timer. Each button
pressed is followed by a buzzer sound.
Switching the Cooking Zones On
Use the corresponding knob to set the
cooking level from 0 to 9. The element is
now ready to use. For fast boil times, keep
the knob at the "P" position for 2 seconds to
activate the Boost function and then adjust
to the desired level.
Switching the Cooking Zones Off
Adjust the knob to"0".
If the cooking zone is hot, "H" will be
displayed instead of "0".
Residual Heat Indicator
The residual heat indicator indicates that
the glass ceramic area has a temperature
that is dangerous to touch.
After switching off the cooking zone, the
respective display will show "H" until the
corresponding cooking zone temperature is
at a safe level.
Safety Switch-Off Function
A cooking zone will automatically switch off
if the heat setting has not been modified
for a specified duration of time. A change
in the heat setting of the cooking zone will
reset the time duration to the initial value.
This initial value depends on the selected
temperature level, as shown below.
2
3
4
5
Heat setting
1-2
3-4
5
6-9
Timer Function
Cooking Zone Timer (1 - 99 min.)
When the hob is switched on, an
independent timer can be programmed for
each cooking zone.
Select a cooking zone, then select the
temperature setting and, finally, activate the
timer setting button
programmed to switch off a cooking zone.
Four LEDs are arranged around the timer
that indicate which cooking zone the timer
has been set for.
10 seconds after the last operation, the
timer display will change to the timer that
will run out next (in cases where a timer is
set for more than one cooking zone).
When the timer has run down, a signal will
sound, the timer display will show ´00` and
the assigned cooking zone timer LED will
blink. The programmed cooking zone will
switch off and "H" will be displayed if the
cooking zone is hot.
The sound signal and the blinking of the
timer LED will stop automatically after 2
minutes and/or by pressing any button.
Buzzer
While the hob is in operation, the following
activities will be signalled by the buzzer.
•
Normal button activation will be
accompanied with a short sound signal.
•
Continuous button operation over a
longer period of time (10 seconds)
will be accompanied with a longer,
intermittent sound signal.
Boost Function
To use this function, select a cooking zone
and set the desired cooking level, then
press the "P" (Boost) button.
The Boost function can only be activated
if it is applicable with the cooking zone
selected. If the Boost Function is active, a
"P" is shown on the corresponding display.
Activating the booster can exceed the
maximum power, in which case the
integrated power management will be
EN - 16
Safety switch off after
6 Hours
5 Hours
4 Hours
1.5 Hours
, the timer can be
