(English) UMS4 User Manual
Automatic Battery Internal Resistance Detection
When the UMS4 is on and the battery is installed, it will automatically detect and display
the Internal Resistance below the "CHG. STATUS". When the Internal Resistance is below
250mΩ, it will show "Good" on the screen. When it is above 250mΩ, it will show "Poor"
on the screen to indicate that the battery should be replaced.
Charged Volume Calculation
During the charging process, the system will automatically calculate and display the
Charged Volume below the "CHG. STATUS".
Anti-short Circuiting and Reverse Polarity Protection
If there are batteries inserted with polar reversed or short-circuited, the screen will flash
to show "EE EE".
Energy Saving Function
If there is no action to the buttons or batteries in 3 minutes, the screen will automatically
go dim to save energy. Perform any action to light up the screen.
Over-Discharged Li-ion Battery Activation
The UMS4 is capable of activating over-discharged Li-ion batteries with a protective
circuit. After battery installation, UMS4 will test and activate the battery before charging.
When a battery is detected as damaged, the screen will show "EE EE".
Over-Discharged IMR Battery Restoration
When an over-discharged IMR battery is inserted, the screen will show "EE EE". In
this case, long press the V button to enter Restoration Mode. After that, the charging
process will continue. The battery should be replaced if it fails to be restored after several
attempts.
NOTE: When attempting to restore an IMR battery, reverse polarity protection is
temporarily disabled. Please ensure batteries are correctly inserted. Failing to do so may
result in fire or explosion.
Overtime Charging Protection
The UMS4 will separately calculate the charging time of each battery. When the charging
time exceeds 20 hours in one slot, it will automatically cease the charging process of this
slot and display "END" below the "CHG. STATUS". This is to prevent possible overheat or
even explosion due to battery quality issue.
Precautions
1. The charger is restricted to charging Li-ion, IMR, LiFePO4, Ni-MH/Ni-Cd rechargeable
batteries only. DO NOT use the charger with other types of batteries as this could
result in battery explosion, cracking or leaking, causing property damage and/or
personal injury.
2. Moderate heat from this product is to be expected during the charging process, which
is normal.
3. Ambient Temperature of Usage: -10~40℃ (14~104℉); Temperature of Storage:
-20~60℃ (-4~140℉)
-4-
4. Carefully read all labels on the device to ensure batteries are installed correctly.
5. Please connect this charger to power supplies with the input voltage stated in the
specifications of the user manual. If the input voltage is too low or too high, it may
lead to malfunctions, or even a fire.
6. DO NOT charge batteries if there is any sign of faulty or short circuit.
7. The charger is designed for adults. Use of the charger by kids under age must be
under supervision. Operation, using or cleaning of the charger may NOT be done by
kids aged 8 years or younger.
8. DO NOT leave the product unattended while it is connected to a power supply.
Unplug the product at any sign of malfunction.
9. Please make sure the correct program and settings are chosen and set. Incorrect
program or setting may damage the charger, or cause fire and explosion.
10. DO NOT attempt to charge primary cells such as Zinc-Carbon, Lithium, CR123A, CR2,
or any other unsupported chemistry due to risk of explosion and fire.
11. DO NOT charge a damaged IMR battery as doing so may lead to charger short-circuit
or even explosion.
12. DO NOT charge or discharge any battery having evidence of leakage, expansion/
swelling, damaged outer wrapper or case, color-change or distortion.
13. Use the original adapter and cord for power supply. To reduce the risk of damage to
the power cord, ALWAYS pull by the connector rather than the cord. DO NOT operate
the charger if it appears damaged in any way.
14. DO NOT store or use the product in an environment where the temperature is
extremely high / low or changes rapidly, or in a confined area with a high temperature.
15. Store the device in ventilated areas. DO NOT use the device in moist environment
and keep away from any combustible materials.
16. Avoid any shock or impact to the device.
17. DO NOT place any conductive or metal object in the device to avoid short circuiting
and explosions.
18. DO NOT overcharge or over-discharge the batteries. Please recharge the battery as
soon as the power runs out.
19. Unplug the device and remove all batteries when it is not in use.
20. DO NOT disassemble or modify the device as doing so will render the product
warranty invalid. Please refer to the warranty section in the manual for complete
warranty information.
21. DO NOT misuse in any way! Use for intended purpose and function only.
Disclaimer
This product is globally insured by Ping An Insurance (Group) Company of China, Ltd.
NITECORE shall not be held responsible or liable for any loss, damage or claim of any kind
incurred as a result of the failure to obey the instructions provided in this user manual.
Warranty Details
Our authorized dealers and distributors are responsible for warranty service. Should
any problem covered under warranty occurs, customers can contact their dealers or
distributors in regards to their warranty claims, as long as the product was purchased
from an authorized dealer or distributor. NITECORE's Warranty is provided only for
products purchased from an authorized source. This applies to all NITECORE products. To
be qualified for warranty, please refer to the "IMPORTANT WARRANTY NOTICE" section
on top to validate your product.
Any DOA / defective product can be exchanged for a replacement through a local
-5-
