General Notes
• Read the instructions carefully before beginning the installation
and carry out the actions as specified by the maker;
• The installation, programming, putting into operation and main-
tenance of the product must be carried out only by qualified
technical personnel, correctly trained with regard to respecting
the regulations in force, including the implementation of acci-
dent prevention measures;
• Before carrying out any cleaning or maintenance operation, dis-
connect the device from the power supply;
• The equipment must be destined solely for the use for which it
was expressly designed.
• The manufacturer declines all liability for any damage as a result
of improper, incorrect or unreasonable use.
• This Product is a combination of a BPT Product and Third Par-
ETH SWITCH
ty products integrated by BPT. The Distributor and the End
J2
User of this Product are not allowed to modify or reproduce
in any way the Product and the documentation, marks, cop-
yrights or other notices related to it, nor to use the Product
ETH SWITCH
or its components into applications other than BPT systems.
J2
The Distributor and End User have to comply fully with all
applicable laws and regulations, in any of its dealings with
respect to the Product, including its exportation.
Installation
• The device must be installed on a DIN rail (EN 50022) in a specific
electrical panel.
A
• For the overall dimensions see figure
.
NOTE. Proper ventilation is required if the device is installed
in a metal container.
Function of connectors
J1: Ethernet Port 10/100 Mb
J2: Ethernet Port 10/100 Mb
CN6: Connector for connection VA/08
CN2: Reserved for future use.
USB: Connector for programming from a PC
Technical features
Type
Power supply (V DC)
Input current- @ 18 V DC (mA)
Input current- @ 14 V DC (mA)
Operating temperature (°C)
Storage temperature (°C)
IP Degree
Terminal boards
Power supply
+
14-18 VDC
–
LED
J8
ACT
Common
C
LED
Input 1
I1
STAT
LED
Input 2
I2
J1
CN2
RST
USB
C I1 I2 I3
J8
ACT
Input 3
I3
LED
Power supply
+
STAT
14-18 VDC
–
CN2
RST
USB
J1
C I1 I2 I3
A
Audio
A
+
Data line
D
–
+
Video signal
V
–
Jumper function "J7"
B
Jumper Position
Meaning
Default entry panel NOT connected to the
CN3 terminal board
J7
Entry panel connected to the CN3
terminal board
J7
Function of "ACT", "STAT" and "Dati" LEDs
LED Name
Colour
Blue
Device status
STAT
green
Activity in progress
ACT
red
Data transmission in progress
DATI
Meaning of "ACT" and "STAT" LEDs
Legenda:
ETI-Xip
off
ON
Slow flashing
,
,
14÷18
300
LED "ACT" LED "STAT"
390
0 ÷ +35
-25 ÷ + 70
30
/
/
Initialisation
The ETI-XIP interface has 2 Ethernet sockets in Switch configura-
tion, or the PC can be connected directly using a Cross cable.
Once the interface is powered, wait for the LED to display the "nor-
mal operation" configuration (see table).
Once the cable is connected and the PC is configured for connec-
tion to the interface, enter the following address in the browser
http://192.168.1.2
C
After a few moments, the web configuration page will appear that
will ask for user credentials, which have the factory configuration
of: Username: installer, Password: 112233.
For complete system configuration, refer to the "Programming
Manual".
DISPOSAL
Do not litter the environment with packaging material: make
sure it is disposed of according to the regulations in force in the
country where the product is to be used.
When the equipment reaches the end of its life cycle, avoid dis-
carding it within the environment.
B
The equipment must be disposed of in compliance with current
regulations, recycling its component parts wherever possible.
Meaning
Components that qualify as recyclable waste feature the relevant
symbol and material acronym.
B
Fast flashing
,
Meaning
FNormal operation:
software loading phase
Normal operation:
software running
Device in maintenance phase:
OPERATION CANNOT BE INTERRUPTED
Program running:
OPERATION CANNOT BE INTERRUPTED
Abnormal operation:
device blocked
Abnormal operation:
device blocked
.
