Items Qty./Unit
Battery Charger 1 set
Spirit External
Battery Cable
1 set
(Purchase Sepa-
rately)
Kill
2 sets
Switch
Steering
2 pcs
Lock Pin
In the Box,
User Manual,
Warranty Card,
1 set
Quality Certifi-
cate & Invitation
Card
Save the ePropulsion original package for the outboard storage.
Other accessories mentioned in this user manual need to be purchased
by users from ePropulsion authorized dealers.
There are currently four types of official chargers for SPIRIT Battery Plus.
The one included in the package is Standard Charger. The other three
are Fast Charger, Solar Charger and DC Charger, which need to be pur-
chased separately by users from ePropulsion authorized dealers.
Figure
In the Box Warranty
Quality
Certificate
Invitation Card
6
1.2 Parts and Diagram
Power Port
Power Cable
Screen Panel
Kill Switch
Throttle Handle Case
Throttle Rubber
Handle
Clamp Tightening Handle
Bracket Clamp
Trim Pin
Shaft
Motor
Anode
Figure 1-1
Battery Handle
Charging Port
Charging Indicator
Battery Lock
Battery Pack
(built-in Li-po
batteries and BMS)
Trim Release Lever
Beaching Pin
Propeller
Skeg
