Ensure to hold the battery handle before detaching or mounting the bat-
tery.
Slot
Block
Figure 3-5
Step3: Plug the power cable in the power port and tighten the connector. The
connector is metal, and it own needs to be figure tight ½ of a turn clockwise.
Figure 3-6
Make sure the power cable connector and socket are dry before con-
necting to avoid short-circuit.
Please spray and clean the connectors about every 3 months with con-
tact spray.
Figure 3-7
18
4 Connecting a 48V Battery
When using a battery, make sure the power switch is off before connection.
1. First connect the external battery cable to the battery.
2. Connect the external battery cable with the power cables from the out-
board.
Figure 4-1
Avoid battery short-circuit during connection.
Do not short-circuit the main switch with other power supplies. The main
switch should be mounted on the boat, and the back plate of the main
switch should not be removed.
Outboard motor will stop working once the power cable disconnects.
Counterclockwisely turn the reset button on the power switch until it is
stuck to power on the battery before use.
Users can also enlarge the battery capacity by connecting multiple bat-
teries in parallel.
During use, if a poor contact is found, it is recommended to check the
tightening of each terminal connection.
2
Main
Switch
1
+ -
48V
19
